Aten CL5816N-ATA-AU 16-Port PS/2-USB VGA Dual Rail LCD
KVM Switch with Daisy-Chain Port and USB Peripheral Support
Features
- Exclusive LED illumination light - designed by ATEN to illuminate the
keyboard and touchpad to allow visibility in low-light conditions
- Integrated KVM console with 19" LED-backlit LCD monitor in a Dual Rail
housing
- Space saving technology - up to two consoles (one bus) control up to 16
computers
- Daisy-chain up to 31 additional units*– control up to 512 computers from
two consoles (one bus)
- Dual Interface - supports computers and console with PS/2 or USB keyboards
and mice
- Supports USB peripherals for computers connected to the local station
- LCD module rotates up to 120 degrees for a more comfortable viewing angle
- Console Lock - enables the console drawer to remain securely locked away
in position when not in use
- Multiplatform support - Windows, Linux, Mac, and Sun
- Supports multimedia USB keyboards for PC, Mac and Sun
- Auto PS/2 and USB interface detection
- Keyboard and mouse emulation (PS/2 and USB) for smooth switching and
simultaneous booting of multiple computers even when the console focus is
elsewhere
- Extra console port - manage computers in the LCD KVM switch from an
external console (monitor, USB keyboard, and USB mouse)
- *With compatible KVM Switches:ACS1208A, ACS1216A,CS1708A,CS1716A
- Supports external USB mouse
- Superior video quality - supports resolutions up to 1280 x 1024 @ 75 Hz
- No software required - convenient computer selection via front panel
pushbuttons, hotkeys, and multilingual on-screen display (OSD) menus
- Auto-senses station's position on daisy chained installations; no need for
manual dip switch setting; front panel led indicates station's position
- Port names automatically reconfigured when station sequence is changed
- Two level password security - only authorized users can view and control
computers
- LCD power button helps save energy and prolong display's life
- Supports one administrator and four user accounts with separate profiles
- Auto Scan mode enables continuous monitoring of user-selected computers
- Broadcast support - commands from the keyboard can be broadcast to all
available computers on the installation
- Hot pluggable - add or remove computers without having to power down the
switch
- Beeper on/off via hotkey and OSD
- Firmware upgrades to all the chained KVM switches at the same time via the
daisy chain cable
- Keyboard Language supports English (US), English (UK), French, German,
German (Swiss), Greek, Hungarian, Italian, Japanese, Korean, Russian, Spanish,
Swedish and Traditional Chinese
Package Contents
- 1x CL5816 KVM Switch with Standard Rack Mounting Kit
- 2x Custom KVM Cable (VGA, USB, PS/2; 1.8m/6ft)
- 1x Custom Console Cable (VGA, USB, PS/2; 27cm/0.88ft)
- 1x Firmware Upgrade Cable
- 1x Power Cord
- 1x User Instructions
Overview
The CL5816 Slideawayâ„¢ Dual Rail LCD KVM Switch is a control unit that allows
access to multiple computers from two PS/2 or USB KVM consoles. An extra console
port is provided on the rear panel to manage the LCD KVM switch from an optional
external consoles.
The CL5816 19" LED-backlit LCD monitor and keyboard/touch pad modules slide
independently of each other. To maximize space in your data center, the
keyboard/touch pad module slides back to "hide away" when not in use, while the
thin profile LCD monitor rotates back - flush against the rack - allowing
convenient monitoring of computer activity. Quickly and conveniently switch
computer access with station and port selection pushbutton switches located on
the keyboard module. Even when the keyboard module is in the retracted position
you can still switch access with the Port Up/Port Down pushbuttons located on
the monitor module. The CL5808 supports both PS/2 and USB keyboards and mice for
the connected computers, and the CL5816 supports USB peripheral devices to be
used with the attached computers. A single CL5816 can control up to 16
computers. As many as 31 additional compatible KVM switches can be daisy chained
together, so that up to 512 computers can all be controlled from a single
keyboard, monitor, and mouse console.
Specifications
Panel
Spec |
|
LCD
Module |
19"
TFT-LCD |
Pixel
Pitch |
0.294
mm x 0.294 mm |
Support
Color |
16.7M
colors |
Contrast
Ratio |
1000:01:00 |
Luminance |
250
cd/m² |
Response
time |
5
ms |
Viewing
Angle |
170°
(H), 160° (V) |
Computer
Connections |
|
Direct |
16 |
Maximum |
512
(via Daisy-chain) |
Port
Selection |
OSD,
Hotkey, Pushbutton |
Connectors |
|
External
Console Ports |
1
x SPHD-18 Male (Yellow) |
External
Mouse Port |
1
x USB Type-A Female |
KVM
Ports |
16
x SPHD-17/18 Female (Yellow) |
Daisy
Chain Ports |
1
x DB-25 Male (Black) |
Firmware
Upgrade |
1
x RJ-11 Female (Black) |
Power |
1
x 3-prong AC Socket |
USB
Port |
1
x USB Type-A Female |
Switches |
|
Reset |
1
x Semi-recessed Pushbutton |
Power |
1
x Rocker |
Firmware
Upgrade |
1
x Slide |
LCD
Adjustment |
4
x Pushbutton |
LCD
On/Off |
1
x LED Pushbutton (Orange) |
Port
Selection |
2
x Pushbutton (LCD); |
|
16
x Pushbutton (Keyboard) |
Station
Selection |
2
x Pushbutton |
LEDs |
|
Online |
16
(Orange) |
Selected |
16
(Green) |
Station
ID |
2
x 7-segment LED Display (Orange) |
Power |
1
(Dark Green) |
Lock |
1
(Green) |
Emulation |
|
Keyboard
/ Mouse |
PS/2,
USB |
Video |
1280
x 1024 @ 75 Hz; DDC2B |
Scan
Interval |
1–255
sec. |
Maximum
Input Power Rating |
100–240V
AC, 50-60Hz, 1A |
Power
Consumption |
120V/26W;
230V/26.8W |
Environmental |
|
Operating
Temperature |
0–50°C |
Storage
Temperature |
-20–60°C |
Humidity |
0–80%
RH, Non-condensing |
Physical
Properties |
|
Housing |
Metal
+ Plastic |
Weight |
14.76
kg ( 32.51 lb ) |
Dimensions
(L x W x H) |
48.00
x 68.04 x 4.40 cm |
|
(18.9
x 26.79 x 1.73 in.) |
Note |
For
some of rack mount products, please note that the standard physical
dimensions of WxDxH are expressed using a LxWxH
format. |
