Function |
VE801R |
VE801T |
|
Video
Input |
|
|
|
Interfaces |
N/A |
1
x HDMI Type A Female (Black) |
|
Impedance |
N/A |
100
Ώ |
|
Max.
Distance |
N/A |
1.8
m |
|
Video
Output |
|
|
|
Interfaces |
1
x HDMI Type A Female (Black) |
N/A |
|
Impedance |
100
Ώ |
N/A |
|
Video |
|
|
|
Max.
Data Rate |
10.2Gbps
(3.4Gbps per lane) |
10.2Gbps
(3.4Gbps per lane) |
|
Max.
Pixel Clock |
340
MHz |
340
MHz |
|
Compliance |
HDMI
(3D, Deep Color, 4K) |
HDMI
(3D, Deep Color, 4K) |
|
|
HDCP
Compatible |
HDCP
Compatible |
|
|
Consumer
Electronics Control (CEC) |
Consumer
Electronics Control (CEC) |
|
Max.
Resolutions / Distance |
Up
to 4K@35m (Cat 5e/6) / 40m (Cat 6a/ATEN 2L-2910 Cat6); |
Up
to 4K@35m (Cat 5e/6) / 40m (Cat 6a/ATEN 2L-2910 Cat6);
|
|
|
1080p@60m
(Cat 5e/6) / 70m (Cat 6a/ATEN 2L-2910 Cat6) |
1080p@60m
(Cat 5e/6) / 70m (Cat 6a/ATEN 2L-2910 Cat6) |
|
|
*4K
supported: |
*4K
supported: |
|
|
4096
x 2160 / 3840 x 2160 @ 60Hz (4:2:0); |
4096
x 2160 / 3840 x 2160 @ 60Hz (4:2:0); |
|
|
4096
x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
4096
x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
|
Audio |
|
|
|
Input |
N/A |
1
x HDMI Type A Female (Black) |
|
Output |
1
x HDMI Type A Female (Black) |
N/A |
|
Connectors |
|
|
|
Power |
1
x DC Jack (Black) with locking |
1
x DC Jack (Black) with locking |
|
Unit
To Unit |
1
x RJ-45 Female |
1
x RJ-45 Female |
|
Power
Consumption |
DC5V:1.86W:9 |
DC5V:4.24W:20 |
|
Environmental |
|
|
|
Operating
Temperature |
0-50°C |
0-50°C |
|
Storage
Temperature |
-20
- 60°C |
-20
- 60°C |
|
Humidity |
0%
- 80% RH, Non-condensing |
0%
- 80% RH, Non-condensing |
|
Physical
Properties |
|
|
|
Housing |
Metal |
Metal |
|
Weight |
0.25
kg ( 0.55 lb ) |
0.24
kg ( 0.53 lb ) |
|
Dimensions
(L x W x H) with bracket |
9.86
x 8.70 x 3.00 cm |
9.86
x 8.70 x 3.00 cm |
|
|
(3.88
x 3.43 x 1.18 in.) |
(3.88
x 3.43 x 1.18 in.) |
|
Dimensions
(L x W x H) without bracket |
9.42
x 6.60 x 2.90 cm |
9.42
x 6.60 x 2.90 cm |
|
|
(3.71
x 2.6 x 1.14 in.) |
(3.71
x 2.6 x 1.14 in.) |
