Output |
|
|
Max
Configurable Power (Watts) |
15.0kWatts
/ 15.0kVA |
|
Output
Voltage Distortion |
Less
than 3 % |
|
Output
Frequency (sync to mains) |
50
Hz Sync to mains, 60 Hz Sync to mains |
|
Other
Output Voltages |
380 V,
415 V |
|
Topology
|
Double
conversion online |
|
Output
Voltage THD |
<
3% linear load |
|
Output
Voltage Tolerance |
+/-
1.5 % |
|
Input |
|
|
Input
frequency |
45
- 65 Hz |
|
Input
voltage range for main operations |
304
- 477V |
|
Input
Total Harmonic Distortion |
Less
than 3 % for full load |
|
Other
Input Voltages |
380 V,
415 V |
|
Input
Power Factor at Full Load |
0.99 |
|
Batteries
& Runtime |
|
|
Battery
type |
VRLA |
|
Nominal
Battery Voltage |
240
V |
|
Battery
Slots Empty |
3 |
|
End
of Discharge Battery Voltage |
+/-
198 V DC |
|
Maximum
Available Short Circuit Current |
10kAmps |
|
Communications
& Management |
|
|
Interface
Port(s) |
E3S_Parallel,
E3S_TempSensor |
|
Physical |
|
|
Maximum
Height |
1400MM,
140.0CM |
|
Maximum
Width |
380MM,
38.0CM |
|
Maximum
Depth |
928MM,
92.8CM |
|
Net
Weight |
112.0KG |
|
Shipping
weight |
145.0KG |
|
Shipping
Height |
1640MM,
164.0CM |
|
Shipping
Width |
563MM,
56.3CM |
|
Shipping
Depth |
1014MM,
101.4CM |
|
Color
|
White |
|
Environmental |
|
|
Operating
Temperature |
0
- 40 C |
|
Operating
Relative Humidity |
0
- 95 (Non-condensing) % |
|
Operating
Elevation |
0
- 1015.9meters |
|
Storage
Temperature |
-15
- 40 C |
|
Storage
Relative Humidity |
0
- 95 (Non-condensing) % |
|
Storage
Elevation |
0
- 15240meters |
|
Audible
noise at 1 meter from surface of unit |
60.0dBA |
|
Online
thermal dissipation |
852.0BTU/hr |
|
Protection
Class |
IP20 |
|
Conformance |
|
|
Approvals
|
CE,
EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B,
RCM |
|
Standard
warranty |
1
year on-site repair or replace with factory authorized
Start-Up |
|
Sustainable
Offer Status |
|
|
RoHS
|
Compliant |
