CPU |
AMD Ryzen 5000 Series/
5000 G-Series/
4000 G-Series/ 3000 Series Desktop Processors |
|
*Refer
to www.asus.com for CPU support list. |
Chipset |
B550 |
Memory |
4
x DIMM, Max. 128GB, DDR4
4866(OC)/4800(OC)/4600(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133
MHz, Un-buffered Memory* |
|
Dual
Channel Memory Architecture |
|
*
ECC Memory (ECC mode) support varies by CPU. |
|
*
Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and
memory frequency support depends on the CPU
types. |
Graphics |
1
x DisplayPort 1.2 |
|
1
x HDMITM 2.1(4K@60HZ) |
|
*Graphics
specifications may vary between CPU types. |
Expansion
Slots |
AMD
Ryzen 5000 Series/ 3000 Series Desktop
Processors |
|
1
x PCIe 4.0 x16 slot (supports x16 mode) |
|
AMD
Ryzen 5000 G-Series/ 4000 G-Series Desktop
Processors |
|
1
x PCIe 3.0 x16 slot (supports x16 mode) |
|
AMD
B550 Chipset |
|
1
x PCIe 3.0 x16 slot (supports x4 mode)* |
|
3
x PCIe 3.0 x1 slot* |
|
*PCIE
3.0 X16_2 runs x1 mode when any of the PCIe 3.0 x1 slots is
occupied. |
|
**Support
PCIe bifurcation for RAID on CPU function. |
Storage |
AMD
Ryzen 5000 Series/ 3000 Series Desktop Processors
: |
|
M.2_1
slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA
modes) |
|
AMD
Ryzen 5000 G-Series/ 4000 G-Series Desktop
Processors |
|
M.2_1
slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA
modes) |
|
AMD
B550 Chipset |
|
M.2_2
slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA
modes)* |
|
6
x SATA 6Gb/s ports |
|
Support
Raid 0, 1, 10 |
|
*M2_2
shares bandwidth with SATA6G_56. When M.2_2 is populated, SATA6G_56 will
be disabled. |
Wireless
& Bluetooth |
2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) + BT5.2 |
|
2x2
Wi-Fi 6 (802.11 a/b/g/n/ac/ax) |
|
Supports
2.4/5GHz frequency band |
|
Bluetooth
v5.2* |
|
*Bluetooth
v5.2 function will be ready in Windows 11 or
later. |
USB |
Rear
USB:Total 8 ports |
|
2
x USB 3.2 Gen 2 ports (1 x Type-A + 1 x USB
Type-C) |
|
4
x USB 3.2 Gen 1 ports (4 x Type-A) |
|
2
x USB 2.0 ports (2 x Type-A) |
|
Front
USB:Total 6 ports |
|
1
x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1
ports |
|
2
x USB 2.0 headers support additional 4 USB 2.0
ports |
Audio |
Realtek
7.1 Surround Sound High Definition Audio
CODEC* |
|
-
Supports: Jack-detection, Multi-streaming, Front Panel
Jack-retasking |
|
-
Supports up to 24-Bit/192 kHz playback" |
|
Audio
Features |
|
-
Audio Shielding |
|
-
Rear optical S/PDIF out port |
|
-
Premium Japanese audio capacitors |
|
-
Dedicated audio PCB layers |
|
-
Audio Cover |
Back
Panel I/O Ports |
2
x USB 3.2 Gen 2 ports (1 x Type-A + 1 x USB
Type-C) |
|
4
x USB 3.2 Gen 1 ports (4 x Type-A) |
|
2
x USB 2.0 ports (2 x Type-A) |
|
1
x DisplayPort |
|
1
x HDMI port |
|
1
x ASUS Wi-Fi Module |
|
1
x Realtek 2.5Gb Ethernet port |
|
5
x Audio jacks |
|
1
x Optical S/PDIF out port |
|
1
x BIOS FlashBack button |
Internal
I/O Connectors |
Fan
and Cooling related |
|
1
x 4-pin CPU Fan header(s) |
|
1
x 4-pin CPU OPT Fan header(s) |
|
1
x 4-pin AIO Pump header(s) |
|
3
x 4-pin Chassis Fan header(s) |
|
Power
related |
|
1
x 24-pin Main Power connector |
|
1
x 8-pin +12V Power connector |
|
Storage
related |
|
2
x M.2 slots (Key M) |
|
6
x SATA 6Gb/s ports |
|
USB |
|
1
x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1
ports |
|
2
x USB 2.0 header(s) support(s) additional 4 USB 2.0
ports |
|
Miscellaneous |
|
2
x AURA Addressable Gen 2 header(s) |
|
2
x AURA RGB header(s) |
|
1
x Clear CMOS header |
|
1
x COM Port header |
|
1
x Front Panel Audio header (AAFP) |
|
1
x SPI TPM header (14-1pin) |
|
1
x 20-3 pin System Panel header |
|
1
x Thermal Sensor header |
|
1
x Thunderbolt header |
Special
Features |
ASUS
TUF PROTECTION |
|
-
ASUS DIGI+ VRM (Digital power design with Dr.
MOS) |
|
-
ASUS Enhanced DRAM Overcurrent Protection |
|
-
ASUS ESD Guards |
|
-
TUF LANGuard |
|
-
ASUS Overvoltage Protection |
|
-
ASUS SafeSlot |
|
-
ASUS Stainless-Steel Back I/O |
|
ASUS
Q-Design |
|
-
ASUS Q-DIMM |
|
-
ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow
green]) |
|
-
ASUS Q-Slot |
|
ASUS
Thermal Solution |
|
-
Aluminum M.2 heatsink |
|
ASUS
EZ DIY |
|
-
BIOS FlashBack button |
|
-
BIOS FlashBack LED |
|
-
Procool |
|
AURA
Sync |
|
-
AURA RGB header(s) |
|
-
Addressable Gen 2 RGB header(s) |
Software
Features |
ASUS
Exclusive Software |
|
Armoury
Crate |
|
-
Aura Sync |
|
-
Two-Way AI Noise Cancelation |
|
AI
Suite 3 |
|
-
Performance And Power Saving Utility |
|
TurboV
EVO |
|
EPU |
|
Digi+
VRM |
|
Fan
Xpert 4 |
|
PC
Cleaner |
|
-
EZ update |
|
-
System Information |
|
Aura
Creator |
|
TUF
GAMING CPU-Z |
|
DTS
Custom for GAMING Headsets |
|
Norton
Anti-virus software (Free Trial for 60 days) |
|
WinRAR |
|
UEFI
BIOS |
|
ASUS
EZ DIY |
|
-
ASUS CrashFree BIOS 3 |
|
-
ASUS EZ Flash 3 |
|
-
ASUS UEFI BIOS EZ Mode |
BIOS |
256
Mb Flash ROM, UEFI AMI BIOS |
Operating
System |
Windows
10 64bit |
Form
Factor |
ATX |
|
30.5cm
x 24.4cm |
