Ion F11 2200VA UPS
Overview
ION F11 is a compact line interactive UPS that offers protection from power
surges and failures in the home, office or small business. Ideally suited to
protecting computers and POS devices the ION F11 provides clean, reliable power
delivery. Presented in a stylishly engineered unit, it is compact to fit in
tight spaces and provides multiple power receptacles, HID, SLS, USB
communications port on the 650VA, 1200VA and 2200VA.
- 3 year advanced replacement warranty*
- HID (Human Interface Device) No software installation required
- SLS / Small Load Sensing
- LCD display
- Boost and Buck Automatic Voltage regulation stabilises fluctuating
power
- Easy battery replacement
- USB connection for local interface and communications
- Free software for real time monitoring and safe shutdown of connected
equipment
- Auto-charge even when UPS is off
- Auto-restart in AC power recovery
- Modem/phone line surge protection
- Discharge, overcharge and overload protection
Specifications
|
Output |
|
Output
power capacity |
1200Watts
/ 2200VA |
|
Max
Configurable Power (Watts) |
1200Watts
/ 2200VA |
|
Nominal
Output Voltage |
230V |
|
Output
Voltage Distortion |
Less
than 5% at full load |
|
Output
Frequency (sync to mains) |
47
53 Hz for 50 Hz nominal, 57 63 Hz for 60 Hz
nominal |
|
Topology |
Line
Interactive |
|
Output
Connections |
(4)
Australian 3 pin 10Amp |
|
Transfer
Time |
2-4ms
typical |
|
Input |
|
|
Nominal
Input Voltage |
230V |
|
Input
frequency |
50/60
Hz +/- 3 Hz (auto sensing) |
|
Input
Connections |
2m
IEC to Australian 3 pin plug |
|
Input
voltage range for main operations |
170
280V |
|
Batteries
& Runtime |
|
Battery
type |
Maintenance-free
sealed Lead-Acid battery with suspended electrolyte :
leakproof |
|
Typical
recharge time |
3
hour(s) |
|
Expected
Battery Life (years) |
3-
5 years |
|
Communications
& Management |
|
Interface
Port(s) |
USB |
|
Control
panel |
LCD
status display with On Line : On Battery : Replace Battery and Overload
indicators |
|
Audible
Alarm |
Alarm
when on battery : distinctive low battery alarm : overload continuous tone
alarm |
|
Surge
Protection and Filtering |
|
Surge
energy rating |
320Joules |
|
Data
Line Protection |
RJ-11
Surge Protection |
|
Physical |
|
Maximum
Height |
195mm |
|
Maximum
Width |
139mm |
|
Maximum
Depth |
364mm |
|
Net
Weight |
10.4kg |
|
Shipping
Weight |
11.5kg |
|
Shipping
Height |
220mm |
|
Shipping
Width |
140mm |
|
Shipping
Depth |
340mm |
|
Color |
Black |
|
Environmental |
|
Operating
Environment |
0
40 C |
|
Operating
Relative Humidity |
0
95 % |
|
Operating
Elevation |
0-3000meters |
|
Storage
Temperature |
-15
45 C |
|
Storage
Relative Humidity |
0
95 % |
|
Storage
Elevation |
0-15000meters |
|
Audible
noise at 1 meter from surface of unit |
45.0dBA |
|
Conformance |
|
Approvals |
CE |
|
Standard
warranty |
3
Year Advance Replacement* |
