All stock codes associated to this product
MPZ-D001-SFBP-BAU, MPZD001SFBPBAU
Coolermaster 1300W V SFX Platinum Power Supply
Overview
SFX FORM FACTOR
The V SFX Platinum delivers the high quality experience youve come to expect
from the V series in SFX form factor. Enjoy the same great features with 80 Plus
Platinum efficiency, full-modular cabling, an 92mm fan, 16AWG PCIe high
performance cables, and a 10 year warranty. But now you can have this first
highest power density of SFX PSU in a mini-ITX case. With the V SFX Platinum,
the V series is now viable for cases ranging from mini-ITX all the way up
through E-ATX systems. And with the included bracket this unit is compatible
with all of them.
80 PLUS PLATINUM CERTIFIED
This certification guarantees a typical efficiency of 92% under normal
operating conditions.
Specifications
|
Product
Name |
V1300
SFX Platinum |
|
Product
Number |
MPZ-D001-SFBP-B |
|
ATX
Version |
SFX
12V Ver. 3.42 |
|
PFC |
Active
PFC |
|
Input
Voltage |
100~240V |
|
Input
Current |
7.7A
(Max) |
|
Input
Frequency |
50~60Hz |
|
Dimensions
(L x W x H) |
100
x 125 x 63.5mm |
|
Fan
Size |
92mm |
|
Fan
Bearing |
FDB |
|
Efficiency |
>92%
@ Typical Load |
|
80
PLUS Rating |
80
PLUS Platinum |
|
ErP
2014 Lot 3 |
Yes |
|
Operating
Temperature |
0~50C |
|
Power
Good Signal |
100-150ms |
|
Hold
Up Time |
>16ms |
|
MTBF |
>100,000
hours |
|
Protections |
OVP
/ OPP / SCP / OCP / UVP / OTP / Surge and Inrush
Protection |
|
Regulatory |
TUV,
cTUVus, CE, BSMI, FCC, CCC, EAC, CB, UKCA |
|
Connectors |
ATX
24 Pin |
1x
(300mm) |
|
EPS
4+4 Pin |
1x
(450mm) |
|
EPS
8 Pin |
1x
(450mm) |
|
SATA |
2x
(100 + 150 + 150 + 150mm) (8 connectors) |
|
Peripheral
4 Pin |
1x
(100 + 120 + 120 + 120mm) (4 connectors) |
|
PCI-e
6+2 Pin |
3x
(400 + 120mm) (6 connectors) |
|
PCI-e
Gen 5.0 |
1x
(400mm) |
