Main |
|
Main
Input Voltage |
230
V |
|
Other
Input Voltage |
220
V |
|
240
V |
|
Main
Output Voltage |
230
V |
|
Other
Output Voltage |
220
V |
|
240
V |
|
Rated
power in W |
325
W |
|
Rated
power in VA |
500
VA |
|
output
connector type |
Hard
wire 3-wire (H N + E) 1 |
|
battery
type |
Lead-acid
battery |
|
provided
equipment |
CD
with software |
|
Documentation
CD |
|
Installation
guide |
|
Smart
UPS signalling RS-232 cable |
|
General |
|
Number
of power module filled slots |
0 |
|
Number
of power module free slots |
0 |
|
Redundant |
No |
|
Physical |
|
Height |
14.8
cm |
|
width |
36.2
cm |
|
Depth |
17.1
cm |
|
Net
weight |
12.86
kg |
|
mounting
preference |
No
preference |
|
mounting
mode |
Not
rack-mountable |
|
Two
post mountable |
0 |
|
USB
compatible |
No |
|
Input |
|
input
voltage limits |
151...302
V adjustable |
|
160...285
V |
|
number
of input connectors |
1
hard wire 3-wire (1P + N + E) |
|
network
frequency |
50/60
Hz +/- 3 Hz auto-sensing |
|
Output |
|
Harmonic
distortion |
Less
than 5 % |
|
Maximum
configurable power in VA |
500
VA |
|
Maximum
configurable power in W |
325
W |
|
UPS
type |
Line
interactive |
|
efficiency |
94
% (full load) |
|
output
frequency |
47...53
Hz for 50 Hz nominal sync to mains |
|
57...63
Hz for 60 Hz nominal sync to mains |
|
Conformance |
|
product
certifications |
CE |
|
VDE |
|
standards |
EN/IEC
62040-1:2019/A11:2021 |
|
EN/IEC
62040-2:2006/AC:2006 |
|
EN/IEC
62040-2:2018 |
|
Environmental |
|
Acoustic
level |
55
dBA |
|
Heat
dissipation |
90
Btu/h |
|
Operating
altitude |
0...10000
ft |
|
Ambient
air temperature for operation |
040
C |
|
Ambient
air temperature for storage |
-1545
C |
|
Storage
altitude |
0.0015240.00
m |
|
IP
degree of protection |
IP20 |
|
relative
humidity |
095
% |
|
storage
Relative Humidity |
095
% |
|
Batteries
& Runtime |
|
extended
runtime |
0 |
|
number
of battery filled slots |
1 |
|
Number
of battery free slots |
1 |
|
Battery
recharge time |
2
h |
|
number
of battery replacement quantity |
1 |
|
Battery
life |
35
year(s) |
|
Replacement
battery |
APCRBC135 |
|
|
|
Battery
power in VAH |
120
VAh runtime |
|
battery
charger power |
60
W rated |
|
Communications
& Management |
|
alarm |
Alarm
when on battery : distinctive low battery alarm : overload continuous tone
alarm |
|
Control
panel |
LED
status display with load and battery bar-graphs and on line : on battery :
replace battery : and overload indicators |
|
Emergency
power off |
Yes |
|
Free
slots |
1 |
|
Surge
Protection and Filtering |
|
Surge
energy rate |
540
J |
|
noise
suppression |
Full
time multi-pole noise filtering : 0.3% IEEE surge let-through : zero
clamping response time : meets UL 1449 |
|
Packing
Units |
|
Unit
Type of Package 1 |
PCE |
|
Number
of Units in Package 1 |
1 |
|
Package
1 Height |
29.7
cm |
|
Package
1 Width |
48.1
cm |
|
Package
1 Length |
29.7
cm |
|
Package
1 Weight |
13.32
kg |
|
Contractual
warranty |
|
Warranty |
2
years repair or replace |
