Sony VPLFHZ85B 8000 Lumen Projector
Overview
Powerful, compact, light and superbly styled, these 3LCD laser projectors are
bursting with the latest Sony innovations to deliver consistently rich, bright,
colourful images. With versatile installation options and reduced maintenance
theyre ideal for projection in mid-size corporate, education and public
environments.
Bold, rich colour even in brightly lit rooms
Even powerful projectors can suffer from washed-out image colours in
strongly-lit rooms. Exclusive to Sony, Bright View delivers high-impact images
that dont sacrifice colour. Newly improved Reality Creation ensures images,
diagrams and text look clear and sharp, even in bright conditions. Intelligent
Settings with Ambiance match projected images with your environment for an
enhanced viewing experience: theres even an ambient light sensor to measure room
brightness.
Crisp, high-impact images
The use of 4K photos and videos is increasingly common in presentations.
While the VPL-FHZ85/80 are WUXGA projectors, they offer a 4K60P input to display
images with quality thats close-to-true 4K resolution. Reality Creation is Sonys
processing technology thats been improved for displaying 4K content better,
ensuring images look crisper with a stronger feeling of depth.
Sophisticated design and superior installation
flexibility
The light, compact VPL-FHZ85/80 make an elegant addition to any modern work
space. Its understated blend-in design features a flat top surface that
minimises visual impact when the projector is ceiling mounted. Installation is
simplified with a choice of optional lenses, while a class-leading lens shift
capability overcomes challenges like ceiling obstacles and other AV
equipment.
Brighter for longer
While other projectors can fade over time, the VPL-FHZ85/80 are engineered to
maintain consistent image brightness. An exclusive Intelligent Settings feature
automatically monitors real-world usage, optimising settings to keep images
consistently bright. The sealed laser light source and automated filter cleaning
system prevent dust build-up, ensuring cool, efficient operation with
uncompromised image brightness.
Specifications
|
Display
system |
|
|
Display
system |
3
LCD system |
|
Display
device |
|
|
Size
of effective display area |
New
LCD panel 0.76" (19 mm) x 3 BrightEra LCD Panel, Aspect ratio:
16:10 |
|
Number
of pixels |
6,912,000
(1920 x 1200 x 3) pixels |
|
Projection
lens *1 |
|
|
Focus |
Powered |
|
Zoom
- Powered/Manual |
Powered |
|
Zoom
- Ratio |
Approx.
x 1.6 |
|
Throw
ratio |
1.39:1
to 2.23:1 |
|
Lens
shift - Powered/Manual |
Powered |
|
Lens
shift - Range Vertical |
-5%,
+70% |
|
Lens
shift - Range Horizontal |
+/-
32% |
|
Light
source |
|
|
Type |
Laser
diode |
|
Screen
size |
|
|
Screen
size |
40''
to 600'' (1.02 m to 15.24 m) (measured
diagonally) |
|
Light
output *2 |
|
|
Mode:
Standard |
7300lm
*3 / 8000lm (Center)*4 |
|
Mode:
Middle |
5840lm |
|
Mode:
Low |
- |
|
Colour
light output *2 |
|
|
Mode:
Standard |
7300lm |
|
Mode:
Middle |
5840lm |
|
Mode:
Low |
- |
|
Time
until light output declines to 50 %*5 |
|
|
Mode:
Standard |
20000
hours |
|
Mode:
Middle |
30000
hours |
|
Contrast
ratio (full white / full black) *2 |
|
|
Contrast
ratio (full white / full black) |
:1 |
|
Displayable
scanning frequency |
|
|
Horizontal |
15
kHz to 93 kHz |
|
Vertical |
23
Hz to 63 Hz |
|
Accepted
signal resolution |
|
|
Computer
signal input |
Maximum
signal resolution: 1920 x 1200 *6 |
|
Video
signal input |
NTSC,
PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p,
1080/60i, 1080/50i, 1080/60p, 1080/50p,3840/60p, 3840/30p, 3840/25p,
3840/24p,4096/60p, 4096/30p, 4096/25p,
4096/24p |
|
Keystone
correction (Max.) |
|
|
Horizontal |
+/-
30 degrees |
|
Vertical |
+/-
30 degrees |
|
INPUT
OUTPUT (Computer / Video / Audio / Control) |
|
|
INPUT
A |
RGB
/ Y PB PR input connector:Mini D-sub 15 pin
(female) |
|
Audio
input connector: Stereo mini jack |
|
INPUT
B |
DVI
input connector: DVI-D 24-pin (single link), HDCP
support |
|
Audio
input connector: Shared with INPUT A |
|
INPUT
C |
HDMI
input connector: HDMI 19-pin, HDCP support |
|
Audio
input connector: HDMI audio support |
|
INPUT
D |
HDBaseT
interface connector: RJ45, 4 play (Video, Audio, LAN,
Control) |
|
VIDEO
IN |
Video
input connector: BNC |
|
Audio
input connector: Shared with input A |
|
OUTPUT
A |
Monitor
output for Input A Connector: Mini D-sub 15-pin
(female) |
|
Audio
output connector: Stereo mini jack |
|
OUTPUT
B |
Monitor
output for Input B Connector: DVI-D 24-pin (single link), HDCP not
supported |
|
Audio
output, Monitor out connector: Stereo mini
jack |
|
REMOTE |
D-sub
9-pin (male) / RS232C |
|
LAN |
RJ45,
10BASE-T/100BASE-TX |
|
IR
(Control S) |
Stereo
mini jack, Plug in power DC5V |
|
USB |
TYPE-A
(for F/W update) , TYPE-A (for Power supply) |
|
Acoustic
Noise *2 |
|
|
Acoustic
Noise (Mode: Standard / Middle) |
38
dB / 36 dB |
|
Operating
temperature / Operating humidity |
|
|
Operating
temperature / Operating humidity |
0C
to 45C (32F to 109F) / 20% to 80% (no
condensation) |
|
Storage
temperature / Storage humidity |
|
|
Storage
temperature / Storage humidity |
-10C
to +60C (14F to +140F) / 20% to 80% (no
condensation) |
|
Power
requirements |
|
|
Power
requirements |
AC
100 V to 240 V, 5.1 A to 2.2 A, 50 Hz / 60 Hz |
|
Power
consumption |
|
|
AC
100 V to 120 V |
Mode:
Standard: 506 W |
|
AC
220 V to 240 V |
Mode:
Standard: 474 W |
|
Power
consumption (Standby Mode) |
|
|
AC
100 V to 120 V |
0.5W
(when Standby mode is set to Low) |
|
AC
220 V to 240 V |
0.5W
(when Standby mode is set to Low) |
|
Power
consumption (Networked Standby Mode) |
|
|
AC
100 V to 120 V |
9.8
W (LAN) |
|
10.6
W (HDBaseT) |
|
10.6
W (All Terminals and Networks Connected) (when "Standby Mode" is set to
"Standard") |
|
AC
220 V to 240 V |
10.9
W (LAN) |
|
11.6
W (HDBaseT) |
|
11.6
W (All Terminals and Networks Connected) (when "Standby Mode" is set to
"Standard") |
|
Standby
Mode / Networked Standby Mode Activated |
|
|
Standby
Mode / Networked Standby Mode Activated |
Approx.
10 Minutes |
|
Heat
dissipation |
|
|
AC
100 V to 120 V |
1617
BTU/h |
|
AC
220 V to 240 V |
1727
BTU/h |
|
Dimensions
(W x H x D) |
|
|
Dimensions
(W x H x D) (without protrusions) |
460
x 169 x 494 mm |
|
18
1/8 x 6 3/4 x 19 1/2 inches |
|
Mass
|
|
|
Mass |
Approx.
13 kg (29 lb) |
|
Optional
accessories |
|
|
Projection
Lens |
VPLL-3003
/ 3007 / Z3009 / Z3010 / Z3024 / Z3032 |
|
Notes
|
|
|
*1 |
With
supplied standard lens |
|
*2 |
The
figures are approximate. They vary depending on the environment or how the
projector is used. |
|
*3 |
The
value is in accordance with ISO 21118, and may differ depending on the
actual unit. Brightness and contrast vary depending on use conditions and
environments. |
|
*4 |
The
value is light output measured at centre area of screen in Standard mode,
and average of all products shipped. |
|
*5 |
Estimated
time until light output declines to 50 % varies depending on
environment. |
|
*6 |
Available
for VESA Reduced Blanking
signal. |
