All stock codes associated to this product
FPWTLTBAT, 3695902, 0065030870399
| Mounting |
|---|
| Mounting type | Wall |
| Maximum weight capacity | 40 kg |
| Minimum screen size | 94 cm (37") |
| Maximum screen size | 190.5 cm (75") |
| Panel mounting interface | 300 x 200,300 x 300,400 x 200,400 x 400,400 x 300,600 x 300,600 x 400,800 x 400 |
| Number of displays supported | 1 |
| Minimum VESA mount | 300 x 200 mm |
| Maximum VESA mount | 800 x 400 mm |
| Ergonomics |
|---|
| Built-in spirit level | Yes |
| Tilt angle range | -5 - 10 ° |
| Cable management | No |
| Design |
|---|
| Product colour | Black |
| Cable management | No |
| Certification | CE, REACH |
| Anti-theft function | Yes |
| Housing material | Steel |
| Technical details |
|---|
| Mounting type | Wall |
| Sustainability certificates | RoHS |
| Packaging content |
|---|
| Screws included | Yes |
| Adapter bracket included | Yes |
| Number of adapter brackets included | 2 |
| Decorative cover included | Yes |
| Number of decorative covers included | 2 pc(s) |
| Anchors included | Yes |
| Number of anchors included | 6 |
| Washers included | Yes |
| Number of washers included | 10 |
| Spacer included | Yes |
| Number of spacers included | 16 |
| Number of screws | 30 |
| Manual | Yes |
| Weight & dimensions |
|---|
| Width | 51 mm |
| Height | 440 mm |
| Weight | 3.7 kg |
| Depth (max) | 99.8 cm |
| Packaging data |
|---|
| Package width | 236 mm |
| Package depth | 987 mm |
| Package height | 65 mm |
| Package weight | 4.8 kg |
| Manual | Yes |
| Logistics data |
|---|
| Master (outer) case width | 256 mm |
| Master (outer) case length | 1007 mm |
| Master (outer) case height | 220 mm |
| Products per master (outer) case | 3 pc(s) |
| Harmonized System (HS) code | 85299097 |
| Other features |
|---|
| Mounting type | Wall |
Display Wall Mount | Anti-Theft | For 37" to 75" Displays
Save space while improving the appearance of your work area, with this low-profile TV wall mount. The mount sits close to the wall to support a VESA Mount compliant TV from 37" to 75", and offers theft deterrence as well as titling capability that makes it easy to find the perfect viewing position.
Low-Profile Design for Meeting Areas or Digital Signage
Mount your flat-screen TV or monitor in a location that's convenient for visitors, clients or employees. The wall mount safely and securely supports your TV about two inches (51 mm) from the wall to provide a sleek, low-profile look. Â
It’s ideal for lobbies, hallways, boardrooms, works areas, customer-facing areas or for creating digital signage. The wall mount supports most 37" to 75" (940 to 1905 mm) LED or LCD flat panel TVs weighing up to 88 lb. (40 kg).
Adjust Your Viewing Angle
This TV wall mount tilts -10 to +5 degrees, so you can adjust the angle of your display with ease to customize your viewing experience.
Anti-theft Protection
Engineered with heavy-duty steel, the robust steel TV wall mount securely supports your flat-screen TV, to protect your investment. Ideal for areas with high traffic  and minimal supervision, the TV mount features a steel bar that can be locked into place with a padlock (purchased separately) to deter theft of your equipment. Â
Easy Setup
A built-in level helps to ensure your TV is aligned in a straight position on your wall, to ensure optimum viewing. Â
The FPWTLTBAT is backed by a StarTech.com 5-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Save space with this flat-screen TV wall mount for 37" to 75" TVs (fits curved TVs, with compatible VESA mount)
- Low profile TV mount sits only 2" (51 mm) from the wall; Tilts -10 to +5 degrees for optimal viewing
- Lockable bar securely holds TV and provides theft deterrence (padlock required)
