Power |
---|
Output power capacity | 2.2 kVA |
Output power | 1980 W |
Input operation voltage (min) | 160 V |
Input operation voltage (max) | 283 V |
Emergency Power Off (EPO) | Yes |
Input frequency | 50/60 Hz |
Performance |
---|
UPS topology | Line-Interactive |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 4 ms |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Waveform | Sine |
Power protection features | Overload |
Auto-restart | Yes |
Automatic Voltage Regulation (AVR) | Yes |
LED indicators | Yes |
Audible alarm(s) | Yes |
Features |
---|
Web-based management | Yes |
Management protocols | SNMP, HTTP |
UPS topology | Line-Interactive |
Output power capacity | 2.2 kVA |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 4 ms |
Output power | 1980 W |
Input operation voltage (min) | 160 V |
Input operation voltage (max) | 283 V |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Emergency Power Off (EPO) | Yes |
Waveform | Sine |
Power protection features | Overload |
Auto-restart | Yes |
Automatic Voltage Regulation (AVR) | Yes |
Audible alarm(s) | Yes |
Input frequency | 50/60 Hz |
Ports & interfaces |
---|
Emergency Power Off (EPO) connector | Yes |
AC outlets quantity | 9 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 1 |
Battery |
---|
Battery technology | Sealed Lead Acid (VRLA) |
Number of batteries supported | 4 |
Battery recharge time | 8 h |
Typical backup time at half load | 12 min |
Typical backup time at full load | 3 min |
Battery voltage | 12 V |
Battery capacity | 9 Ah |
Automatic battery test | Yes |
Design |
---|
Form factor | Tower |
Product colour | Black |
LED indicators | Yes |
Technical details |
---|
Suitable for use in country/location | Europe |
Management features |
---|
Web-based management | Yes |
Management protocols | SNMP, HTTP |
Weight & dimensions |
---|
Width | 170 mm |
Depth | 432 mm |
Height | 221 mm |
Weight | 23.3 kg |
Packaging data |
---|
Bundled software | PowerPanel Business Edition |
Other features |
---|
Output connections | 8 x IEC 320 C13, 1 x IEC 320 C19 |
Nominal output voltage | 230 V |
Nominal input voltage | 230 V |
Suitable for use in country/location | Europe |
Packaging content |
---|
Bundled software | PowerPanel Business Edition |
