Power |
---|
Output power capacity | 2.2 kVA |
Output power | 2200 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Power factor | 1 |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Ports & interfaces |
---|
Cable length | 2.4 m |
Socket circuit breaker | Yes |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
Ethernet LAN (RJ-45) ports | 2 |
Performance |
---|
Audible alarm modes | Alarm when on battery, Low battery alarm |
UPS topology | Line-Interactive |
Number of input phases | 1 |
EMI/RFI noise filtering | Yes |
Waveform | Pure sine |
Power protection features | Overload, Short circuit |
Automatic Voltage Regulation (AVR) | Yes |
Noise level | 52.5 dB |
LED indicators | Yes |
Audible alarm(s) | Yes |
Transfer time (Line Mode to Battery Mode) | 4 ms |
Features |
---|
Web-based management | Yes |
Audible alarm modes | Alarm when on battery, Low battery alarm |
UPS topology | Line-Interactive |
Output power capacity | 2.2 kVA |
Number of input phases | 1 |
Output power | 2200 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
EMI/RFI noise filtering | Yes |
Waveform | Pure sine |
Power protection features | Overload, Short circuit |
Power factor | 1 |
Automatic Voltage Regulation (AVR) | Yes |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Power Factor Correction (PFC) type | Active |
Socket circuit breaker | Yes |
Transfer time (Line Mode to Battery Mode) | 4 ms |
Input frequency | 50/60 Hz |
Battery |
---|
Battery technology | Sealed Lead Acid (VRLA) |
Number of batteries supported | 1 |
Battery recharge time | 3 h |
Typical backup time at half load | 11.4 min |
Typical backup time at full load | 3 min |
Hot-swap battery | Yes |
Design |
---|
Rack capacity | 2U |
Form factor | Rackmount/Tower |
Product colour | Black |
Certification | CE , FCC Class B , UL , RCM , VCCI |
Cable length | 2.4 m |
LED indicators | Yes |
Housing material | Metal |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details |
---|
Bypass | GreenPower UPS |
Sustainability certificates | RoHS, ENERGY STAR |
Management features |
---|
Web-based management | Yes |
Weight & dimensions |
---|
Width | 433 mm |
Depth | 412 mm |
Height | 86.5 mm |
Weight | 25.7 kg |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Package weight | 33.5 kg |
Packaging data |
---|
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Package weight | 33.5 kg |
Certificates |
---|
Certification | CE , FCC Class B , UL , RCM , VCCI |
Other features |
---|
Bypass | GreenPower UPS |
