Power |
---|
Output power capacity | 10 kVA |
Output power | 9000 W |
Input operation voltage (min) | 180 V |
Input operation voltage (max) | 280 V |
Output operation voltage (min) | 200 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 50 A |
Efficiency | 95% |
Output power factor | 0.9 |
Input power factor | 0.99 |
Crest factor | 3:1 |
Total Harmonic Distortion (THD) (linear load) | 3% |
Total Harmonic Distortion (THD) (non-linear load) | 5% |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Performance |
---|
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Double-conversion (Online) |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Waveform | Pure sine |
Power protection features | Overload, Short circuit |
Noise level | 65 dB |
Audible alarm(s) | Yes |
Features |
---|
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Double-conversion (Online) |
Output power capacity | 10 kVA |
Output power | 9000 W |
Input operation voltage (min) | 180 V |
Input operation voltage (max) | 280 V |
Output operation voltage (min) | 200 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 50 A |
Efficiency | 95% |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Waveform | Pure sine |
Power protection features | Overload, Short circuit |
Output power factor | 0.9 |
Input power factor | 0.99 |
Crest factor | 3:1 |
Noise level | 65 dB |
Audible alarm(s) | Yes |
Total Harmonic Distortion (THD) (linear load) | 3% |
Total Harmonic Distortion (THD) (non-linear load) | 5% |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Ports & interfaces |
---|
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 11 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler, Terminal |
Power plug | Terminal |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Battery |
---|
Battery technology | Sealed Lead Acid (VRLA) |
Number of batteries supported | 2 |
Battery recharge time | 5 h |
Typical backup time at half load | 11 min |
Typical backup time at full load | 4 min |
Hot-swap battery | Yes |
Battery voltage | 12 V |
Battery capacity | 9 Ah |
Replacement battery cartridge | RBP0072 |
Design |
---|
Rack capacity | 6U |
Form factor | Rackmount/Tower |
Product colour | Black |
Certification | CE , C-Tick |
Housing material | Metal |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 90% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details |
---|
Bypass | Automatic Bypass , Manual Bypass |
Sustainability certificates | RoHS, ENERGY STAR |
Weight & dimensions |
---|
Width | 433 mm |
Depth | 820 mm |
Height | 264 mm |
Weight | 106.5 kg |
Package width | 600 mm |
Package depth | 1115 mm |
Package height | 640 mm |
Package weight | 133 kg |
Packaging data |
---|
Rack mount kit | Yes |
Package width | 600 mm |
Package depth | 1115 mm |
Package height | 640 mm |
Package weight | 133 kg |
Certificates |
---|
Certification | CE , C-Tick |
Other features |
---|
Bypass | Automatic Bypass , Manual Bypass |
Packaging content |
---|
Rack mount kit | Yes |
