Cooling |
---|
Fan diameter | 12 cm |
Number of fans | 1 fan(s) |
Cooling type | Active |
Performance |
---|
On/off switch | Yes |
80 PLUS certification | 80 PLUS Gold |
Purpose | PC |
ATX version | 2.4 |
Certification | cTUVus / TUV / CB / RCM / CE / FCC / BIS / BSMI / UKCA / ICES |
Design |
---|
80 PLUS certification | 80 PLUS Gold |
Certification | cTUVus / TUV / CB / RCM / CE / FCC / BIS / BSMI / UKCA / ICES |
Product colour | White |
Fan diameter | 12 cm |
On/off switch | Yes |
Number of fans | 1 fan(s) |
Cooling type | Active |
Power |
---|
Total power | 850 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Input current | 10 A |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 100 W |
Combined power (+12V) | 840 W |
Combined power (+5V) | 100 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 12.5 W |
Max output current (+3.3V) | 20 A |
Max output current (+12V) | 70 A |
Max output current (+5V) | 20 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 2.5 A |
Power protection features | Over power, Over voltage, Overcharge, Short circuit, Under voltage |
Efficiency | 92% |
Ports & interfaces |
---|
Motherboard power connector | 20+4 pin ATX |
Number of SATA power connectors | 10 |
Peripheral (Molex) power connectors (4-pin) | 5 |
PCI Express power connectors (6+2 pin) | 6 |
CPU power connector (4+4 pin) | Yes |
ATX power connector (20+4 pin) | Yes |
PCI Express connector | Yes |
Floppy drive power connector | 1 |
Floppy disk drive connector | Yes |
Cabling type | Modular |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions |
---|
Width | 140 mm |
Depth | 150 mm |
Height | 86 mm |
Weight | 1.38 kg |
Packaging data |
---|
Cables included | PCIe, Peripheral (Molex), SATA |
Package type | Box |
Package weight | 2.25 kg |
Certificates |
---|
80 PLUS certification | 80 PLUS Gold |
Certification | cTUVus / TUV / CB / RCM / CE / FCC / BIS / BSMI / UKCA / ICES |
Packaging content |
---|
Cables included | PCIe, Peripheral (Molex), SATA |
