Power |
---|
Output power capacity | 6 kVA |
Output power | 5400 W |
Input operation voltage (min) | 110 V |
Input operation voltage (max) | 276 V |
Output operation voltage (min) | 208 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 445 J |
Maximum current | 27.3 A |
Emergency Power Off (EPO) | Yes |
Output power factor | 0.9 |
Input power factor | 0.99 |
Crest factor | 3:1 |
Efficiency (On-line mode) | 96% |
Total Harmonic Distortion (THD) (linear load) | 2% |
Total Harmonic Distortion (THD) (non-linear load) | 5% |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Battery |
---|
Battery type | BPSE240V75ART3U |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 7 h |
Typical backup time at half load | 16.4 min |
Typical backup time at full load | 6 min |
Battery voltage | 12 V |
Battery capacity | 7 Ah |
Performance |
---|
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Double-conversion (Online) |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Waveform | Sine |
Power protection features | Input fuse, Over current, Short circuit |
Noise level | 60 dB |
Audible alarm(s) | Yes |
Overload capacity (10 minutes) | 125% |
Overload capacity (1 minute) | 150% |
Overload capacity - battery mode (1 minute) | 150% |
Features |
---|
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Double-conversion (Online) |
Output power capacity | 6 kVA |
Output power | 5400 W |
Input operation voltage (min) | 110 V |
Input operation voltage (max) | 276 V |
Output operation voltage (min) | 208 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 445 J |
Maximum current | 27.3 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Emergency Power Off (EPO) | Yes |
Waveform | Sine |
Power protection features | Input fuse, Over current, Short circuit |
Output power factor | 0.9 |
Input power factor | 0.99 |
Crest factor | 3:1 |
Noise level | 60 dB |
Audible alarm(s) | Yes |
Overload capacity (10 minutes) | 125% |
Overload capacity (1 minute) | 150% |
Overload capacity - battery mode (1 minute) | 150% |
Efficiency (On-line mode) | 96% |
Total Harmonic Distortion (THD) (linear load) | 2% |
Total Harmonic Distortion (THD) (non-linear load) | 5% |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Ports & interfaces |
---|
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 1 AC outlet(s) |
AC outlet types | Terminal |
Power plug | Terminal |
Parallel ports quantity | 4 |
Design |
---|
Rack capacity | 3U |
Form factor | Rackmount/Tower |
Product colour | Black |
Certification | CE |
Housing material | Metal |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 90% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 1000 m |
Non-operating altitude | 0 - 50000 m |
Technical details |
---|
Sustainability certificates | RoHS |
Weight & dimensions |
---|
Width | 438 mm |
Depth | 680 mm |
Height | 130.5 mm |
Weight | 17.5 kg |
Packaging data |
---|
Rack mount kit | Yes |
Certificates |
---|
Certification | CE |
Other features |
---|
Battery type | BPSE240V75ART3U |
Packaging content |
---|
Rack mount kit | Yes |
