Power |
---|
Output power capacity | 1 kVA |
Output power | 900 W |
Output operation voltage (min) | 200 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 1872 J |
Efficiency | 87% |
Emergency Power Off (EPO) | Yes |
Power factor | 0.8 |
Input power factor | 0.99 |
Crest factor | 3:1 |
ECO mode | Yes |
Input frequency | 40 - 70 Hz |
Performance |
---|
UPS topology | Double-conversion (Online) |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 4 ms |
Waveform | Pure sine |
Power protection features | Overcharge, Overdischarge, Overload, Short circuit |
Noise level | 50 dB |
Features |
---|
UPS topology | Double-conversion (Online) |
Output power capacity | 1 kVA |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 4 ms |
Output power | 900 W |
Output operation voltage (min) | 200 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 1872 J |
Efficiency | 87% |
Emergency Power Off (EPO) | Yes |
Waveform | Pure sine |
Power protection features | Overcharge, Overdischarge, Overload, Short circuit |
Power factor | 0.8 |
Input power factor | 0.99 |
Crest factor | 3:1 |
Noise level | 50 dB |
ECO mode | Yes |
Input frequency | 40 - 70 Hz |
Power source type | AC |
Detachable power cord | Yes |
Ports & interfaces |
---|
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler |
RS-232 ports | 1 |
USB port type | USB Type-B |
Battery |
---|
Battery technology | Lithium Iron Phosphate (LiFePO4) |
Number of batteries supported | 1 |
Battery recharge time | 2 h |
Battery voltage | 12 V |
Battery capacity | 9 Ah |
Design |
---|
Form factor | Rackmount/Tower |
Product colour | Black |
Certification | EN62040-1-1 2003, IEC60950-1-1 / EN62040-2 2006 / Directive 2011/65/EU |
Cooling type | Active |
Built-in fan | Yes |
Control type | Buttons |
Display type | LCD |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 20 - 90% |
Technical details |
---|
Sustainability certificates | RoHS |
Cooling |
---|
Cooling type | Active |
Built-in fan | Yes |
Weight & dimensions |
---|
Width | 438 mm |
Depth | 380 mm |
Height | 88 mm |
Weight | 10.2 kg |
Certificates |
---|
Certification | EN62040-1-1 2003, IEC60950-1-1 / EN62040-2 2006 / Directive 2011/65/EU |
