All stock codes associated to this product
LH13QBRTMGCXXY, 5900188, 8806095047584
Improved engagement with intuitive interaction
This touch-enabled small display provides a unique store experience and improves customer engagement, delivering content up close in a compact design. It enables efficient content operation and reliable performance for any business use.
Improved engagement with intuitive interaction
This touch-enabled small display provides a unique store experience and improves customer engagement, delivering content up close in a compact design. It enables efficient content operation and reliable performance for any business use.
Crisp content on non-glare panel
The display supports 1920x1080 FHD resolution, displaying crisp and easy-to-read content. This is enhanced by a non-glare panel which delivers clear content in ambient light. These innovative features are supported by reliable operation up to 16 hours a day, suitable for professional use.
Slim, smart design
The compact and slim design of the QB13R-T allows for efficient space utilisation, even in compact locations. A sleek back design makes the display optimal for both wall mounting or simply standing, while the connectivity, content play and device controls are easy to operate.
Powerful content playback
With an embedded MagicINFO S player, backed by TIZEN, the QB13R-T allows efficient and seamless playback without any external media player. SSSP (Samsung Smart Signage Platform) also allows easy content development through reinforced compatibility with multiple web formats.
Comprehensive security setup
The powerful Knox security system provides rigid, three-layer security, offering airtight protection at the application, platform and system level, while restricting access to content and hardware. In addition, remote control of the network and USB ports prevents any unauthorised access.
Convenient, clean display control
With centre Infrared Receiver (IR), each display receives IR signals direct to the panel, allowing easy and convenient remote control even with a tailored installation. When mounted, display doesn't require an IR receiver cabling extension. Built-in Wi-Fi allows wireless remote management for both content and display.
Safe operation, reliable performance
The QB13R-T is electromagnetic compatibility (EMC) class B compliant, meeting strict safety and reliability standards for operation. Additionally, IP5x rating ensures durable performance even in dusty environments.
Diagonal Size | 13" |
Panel Type | Edge LED |
Resolution | 1,920 x 1,080 |
Pixel Pitch (HxV) | 0.153 (H) x 0.153 (V) |
Brightness (Typical) | 500 (w/o Glass) nit |
Contrast Ratio | 600:1 |
Viewing Angle (H/V) | 178/178 |
Response Time | 8ms |
Color Gamut | 45% |
Glass Haze | 25%, 10%(glass) |
Dynamic Contrast Ratio | MEGA |
HDMI In | 1 |
USB | 1 |
RS232 In | Yes |
RJ45 In | Yes |
WIFI | Yes |
Power Supply | AC100-240V 50/60Hz |
Set Dimension (WxHxD) | 322 x 193.5 x 29.8 mm |
Package Dimension (HxWxD) | 376 x 132 x 248 mm |
Net Weight | 1.1 kg |
Package Weight | 2.0 kg |
VESA Mount | 100 x 100 mm |
Bezel Width | 13.1 |
Frame Material | Non-Glossy |
MagicInfo Daisychain Videowall Support | No |
Operating Time | 16/7 |
