| Resolution | 3,840 x 2,400 (4K UHD) / 2,716 x 1,600 (WQXGA+ native) |
| Brightness | 9,000 center lumens* |
| Contrast ratio | 1,200:1 sequential, 10,000:1 dynamic** |
| Brightness uniformity | > 90% |
| Aspect ratio | 16:10 |
| Lens type | GLD/FLDX/FLD+(lens adapter needed) |
| Optical lens shift | Vertical up to 125%, depending on lens, Horizontal up to 50%, depending on lens, Motorized zoom and focus (with lens memory on GLD and FLDX lenses) Motorized lens shift (with position memory on all lenses) |
| Color correction | P7 RealColorâ„¢ |
| CLO (constant light output) | Yes |
| Light source | Laser phosphor |
| Light source lifetime | > 20000 h in normal mode, > 12000 h in silent mode, > 40000 h in long life mode, > 12000 h in high brightness mode |
| Sealed DLPâ„¢ core | Yes |
| Orientation | 360° rotation, no restrictions |
| 3D | Active stereoscopic 3D / Passive stereo compatible |
| Image processing | Embedded warp &lend engine |
| Keystone correction | Yes |
| Inputs | 12G-SDI, 2x DP 1.2, 2x dual link DVI-D, HDBaseT, HDMI2.0 (HDCP2.2, HDR10), RJ 45 Ethernet, DMX in/out*, RS232 in, 2x USB, 12V out |
| Input resolutions | Up to 4K UHD @ 60Hz / Up to 2,560 x 1,600 @ 120Hz. Refresh rates: 24Hz to 120Hz for WQXGA+ (2716x1600) and 24Hz to 60Hz for 4K/4KUHD (4096 x 2160/ 3860 x 2400) |
| Software tools | Projector Toolset |
| Control | IR, RS232, RJ45, XLR wired |
| Network connection | 10/100 Ethernet, RJ45 |
| Power requirements | 100-240V / 50-60Hz |
| 24/7 operation | Yes |
| Power consumption | 950 W nominal, 1100 W maximum |
| BTU per hour | 3,250 BTU/h nominal, 3,800 BTU/h maximum |
| Standby power | <0.5W |
| Noise level (typical at 25°C/77°F) | 35 dB(A) |
| Operating temperature | 10°C (50°F)- 40°C (104°F) (up to 1500m altitude) / 10° (50°F) - 35°C (95°F) (up to 3000m altitude) |
| Storage temperature | -20 to 60 °C |
| Operating humidity | 20-80% RH (non-condensed) |
| Storage humidity | 20-90% RH (non-condensed) |
| Dimensions (WxLxH) | 480 x 680 x 227 mm / 18.9 x 26.7 x 8.9 in |
| Weight | 25.5 kg / 56.2 lbs |
| Standard accessories | Power cord, wireless remote control |
| Certifications | CE, FCC Class A, cNemkoUS, CCC, EAC, KSA, RCM, UkrSEPRO |
| Warranty | Limited 3 years parts and labor. Extendable up to 5 years |
