| Resolution | 1,920 x 1,200 (WUXGA) |
| Brightness | 7,300 ANSI lumens 7,700 center lumens 8,200 ISO lumens |
| Contrast ratio | 1,200:1 sequential; 6,000:1 dynamic; Extreme black: 100,000:1 |
| Brightness uniformity | 85% |
| Aspect ratio | 16:10 |
| Lens type | G-lenses - 0.36:1 / 0.75-0.95:1 / 0.95-1.22:1 / 1.22-1.52:1 / 1.52-2.92:1 / 2.90-5.50:1 |
| Optical lens shift | Vertical up to 100%, depending on lens, Horizontal up to 30%, depending on lens, Motorized zoom and focus, Motorized lens shift |
| Color correction | Yes |
| CLO (constant light output) | Yes |
| Light source | Laser phosphor |
| Light source lifetime | Up to 20,000hrs |
| Sealed DLPâ„¢ core | Yes |
| Orientation | 360° rotation, no restrictions |
| 3D | Active stereoscopic 3D |
| Image processing | Embedded warp &blend possible via Ptoolset |
| Keystone correction | Yes |
| Inputs | 2x HDMI 1.4 / DVI-D / HDBaseT / 3G-SDI / VGA (D-Sub 15 pin) / RJ 45 Ethernet / RS232 in |
| Input resolutions | Up to 1,920 x 1,200 @ 60Hz, refresh rates: 24Hz to 120Hz for 720p (1280x720) and 24Hz to 60Hz for WUXGA (1920x1200) |
| Software tools | Projector Toolset |
| Control | IR, RS232, RJ45, 3.5mm phone jack for wired remote |
| Network connection | 10/100 Ethernet, RJ45 |
| Power requirements | 100-240V / 50-60Hz |
| Power consumption | 635W nominal, 730W maximum |
| BTU per hour | 2,170 BTU/h nominal; 2,500 BTU/h maximum |
| Standby power | less than 0.5W |
| Noise level (typical at 25°C/77°F) | 36dB(A) - 40dB(A) depending on the used mode |
| Operating temperature | 5 - 40 °C (sea level) |
| Storage temperature | -10 to 60 °C |
| Operating humidity | 10 - 85% RH, non-condensing |
| Storage humidity | 5 - 90% RH, non-condensing |
| Dimensions (WxLxH) | without feet: 484 x 529 x 195 mm / 19.06 x 20.83 x 7.68 in |
| Weight | without lens: 17.4 kg / 38.4 lbs |
| Standard accessories | Power cord, wireless remote control |
| Certifications | CE, FCC Class A, cTUVUS, CCC, EAC, KCC, RCM, BIS, BSMI |
| Warranty | Limited 3 years parts and labor |
