| Virtual LAN features |
|---|
| VLAN support | Yes |
| Virtual LAN features | Private VLAN |
| Power |
|---|
| Power connector | AC-in jack |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power source | AC |
| Management features |
|---|
| Switch type | Managed |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Ports &interfaces |
|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | 2 |
| Power connector | AC-in jack |
| Network |
|---|
| Networking standards | IEEE 802.1x, IEEE 802.3at |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| 10G support | No |
| Virtual LAN features | Private VLAN |
| Data transmission |
|---|
| Jumbo frames | 9216 |
| MAC address table | 8000 entries |
| Switching capacity | 20 Gbit/s |
| Throughput | 14.9 Mpps |
| Jumbo frames support | Yes |
| Security |
|---|
| BPDU filtering/protection | Yes |
| SSH/SSL support | Yes |
| Access Control List (ACL) | Yes |
| Password protection | Yes |
| DHCP features | DHCP server, DHCP snooping |
| Protocols |
|---|
| Supported network protocols | IPv4, IPv6, HTTP, HTTPS, QoS, Bonjour, UPnP, SNMP v1/v2c/v3, DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH, STP, RSTP, MSTP, LLDP, LLDP-MED, TFTP, SMTP, BPDU |
| Design |
|---|
| Rack mounting | Yes |
| Product colour | Black |
| Housing material | Metal |
| Certification | EN 55032 Class A, EN 55035, FCC part 15 Subpart B Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, ICES-003 Class A |
| Performance |
|---|
| Fanless | Yes |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) power per port | 30 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 130 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 50 C |
| Storage temperature (T-T) | -10 - 70 C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight &dimensions |
|---|
| Width | 220 mm |
| Depth | 242 mm |
| Height | 44 mm |
| Weight | 2.1 kg |
| Packaging data |
|---|
| User guide | Yes |
| Cables included | AC |
| Packaging content |
|---|
| User guide | Yes |
| Cables included | AC |
