| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 12 |
| Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian |
| PTZ modes | Digital PTZ |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Certification | CISPR 24, CISPR 35, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), KC KN32 Class A, KC KN35, RCM AS/NZS CISPR 32 Class A, VCCI Class A IEC/EN 62368-1, IEC 62471, IS 13252 IEC 60068-2-X, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK08 NIST SP500-267 |
| Design |
|---|
| IK code | IK08 |
| Form factor | Bullet |
| Product colour | White |
| Mounting type | Ceiling/wall |
| Protection features | Dust resistant, Vandal proof, Water resistant |
| International Protection (IP) code | IP66, IP67 |
| Housing material | Aluminium, Plastic |
| Camera |
|---|
| White balance | Auto |
| Camera shutter speed | 1/38500 - 1/5 s |
| Lens viewing angle, horizontal | 130 |
| Lens viewing angle, vertical | 81 |
| Image sensor |
|---|
| Sensor type | CMOS |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 2.1 |
| Closest focusing distance | 0.5 m |
| Fixed focal length | 2.4 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 20 m |
| LED type | IR |
| Infra-red wavelength | 855 nm |
| Video |
|---|
| Text caption overlay | Yes |
| Privacy masking | Yes |
| Image stabilizer | Yes |
| Maximum resolution | 2304 x 1728 pixels |
| Supported graphics resolutions | 2668 x 1512, 2304 x 1728 |
| Supported video modes | 1440p |
| Video compression formats | H.264, H.265, M-JPEG |
| Video streaming | Yes |
| Total megapixels | 4 MP |
| Video intelligence analytic | Yes |
| Video recording | Yes |
| Network |
|---|
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN | Yes |
| Supported network protocols | IPv4, IPv6 USGv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, DHCPv4/v6, SOCKS, SSH, LLDP, MQTT v3.1.1 |
| Storage |
|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC |
| Built-in HDD | No |
| Internal memory | 1024 MB |
| Flash memory | 512 MB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Alert notification type | E-mail |
| Video motion detection | Yes |
| Security algorithms | 802.1x RADIUS, EAP-TLS, HTTPS, SSH |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Active tampering alarm | Yes |
| Password protection | Yes |
| Power |
|---|
| Power source type | PoE |
| Power consumption (typical) | 5 W |
| Power consumption (max) | 12.95 W |
| Certificates |
|---|
| Certification | CISPR 24, CISPR 35, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), KC KN32 Class A, KC KN35, RCM AS/NZS CISPR 32 Class A, VCCI Class A IEC/EN 62368-1, IEC 62471, IS 13252 IEC 60068-2-X, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK08 NIST SP500-267 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 50 C |
| Storage temperature (T-T) | -40 - 65 C |
| Operating relative humidity (H-H) | 10 - 100% |
| Weight & dimensions |
|---|
| Diameter | 10.1 cm |
| Length | 170 mm |
| Weight | 491 g |
| Packaging content |
|---|
| Number of cameras | 1 |
| Technical details |
|---|
| Doesn't contain | BFR, PVC |
| Other features |
|---|
| Video compression formats | H.264, H.265, M-JPEG |
| Logistics data |
|---|
| Harmonized System (HS) code | 85258900 |
