| Design |
|---|
| Backlight colour | Red/Green/Blue |
| Backlight | Yes |
| Cooling type | Heatsink |
| JEDEC standard | Yes |
| Memory |
|---|
| Buffered memory type | Unregistered (unbuffered) |
| Intel Extreme Memory Profile (XMP) | Yes |
| Internal memory | 32 GB |
| Internal memory type | DDR4 |
| Memory clock speed | 3600 MHz |
| Component for | PC/Server |
| ECC | No |
| Intel Extreme Memory Profile (XMP) version | 2.0 |
| Memory layout (modules x size) | 2 x 16 GB |
| Memory form factor | 288-pin DIMM |
| CAS latency | 18 |
| Memory voltage | 1.35 V |
| Lead plating | Gold |
| Module configuration | 2048M x 64 |
| Row cycle time | 45.75 ns |
| Refresh row cycle time | 350 ns |
| Row active time | 32 ns |
| SPD profile | Yes |
| Memory ranking | 1 |
| Programming power voltage (VPP) | 2.5 V |
| Features |
|---|
| Buffered memory type | Unregistered (unbuffered) |
| Intel Extreme Memory Profile (XMP) | Yes |
| Internal memory | 32 GB |
| Internal memory type | DDR4 |
| Memory clock speed | 3600 MHz |
| Component for | PC/Server |
| ECC | No |
| Intel Extreme Memory Profile (XMP) version | 2.0 |
| Backlight colour | Red/Green/Blue |
| Backlight | Yes |
| Memory layout (modules x size) | 2 x 16 GB |
| Memory form factor | 288-pin DIMM |
| CAS latency | 18 |
| Memory voltage | 1.35 V |
| Lead plating | Gold |
| Module configuration | 2048M x 64 |
| Row cycle time | 45.75 ns |
| Refresh row cycle time | 350 ns |
| Row active time | 32 ns |
| SPD profile | Yes |
| Country of origin | China, Taiwan |
| Cooling type | Heatsink |
| Memory ranking | 1 |
| Programming power voltage (VPP) | 2.5 V |
| JEDEC standard | Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Weight & dimensions |
|---|
| Width | 7.1 mm |
| Depth | 133.4 mm |
| Height | 41.1 mm |
| Weight | 77.9 g |
| Package width | 121.9 mm |
| Package depth | 14 mm |
| Package height | 171.5 mm |
| Package weight | 120.5 g |
| Packaging data |
|---|
| Package width | 121.9 mm |
| Package depth | 14 mm |
| Package height | 171.5 mm |
| Package weight | 120.5 g |
| Logistics data |
|---|
| Master (outer) case width | 190.5 mm |
| Master (outer) case length | 254 mm |
| Master (outer) case height | 88.9 mm |
| Master (outer) case gross weight | 1.39 kg |
| Products per master (outer) case | 10 pc(s) |
| Other features |
|---|
| Country of origin | China, Taiwan |
