Power |
---|
Output frequency | 50/60 Hz |
Output power capacity | 10 kVA |
Output power | 10000 W |
Input operation voltage (min) | 110 V |
Input operation voltage (max) | 300 V |
Output operation voltage (min) | 200 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 1335 J |
Emergency Power Off (EPO) | Yes |
Output voltage Total Harmonic Distortion (THD) | 3% |
Output power factor | 1 |
Input power factor | 0.99 |
Input current Total Harmonic Distortion (THD) | 1.5% |
Crest factor | 3:1 |
Charging current | 4 A |
Efficiency (ECO mode) | 98% |
ECO mode | Yes |
Input frequency | 50/60 Hz |
Performance |
---|
Audible alarm modes | Battery replacement, Fault, Overload alarm |
UPS topology | Double-conversion (Online) |
EMI/RFI noise filtering | Yes |
Waveform | Pure sine |
Power protection features | Overload |
Noise level | 62 dB |
Audible alarm(s) | Yes |
Features |
---|
Output frequency | 50/60 Hz |
Audible alarm modes | Battery replacement, Fault, Overload alarm |
UPS topology | Double-conversion (Online) |
Output power capacity | 10 kVA |
Output power | 10000 W |
Input operation voltage (min) | 110 V |
Input operation voltage (max) | 300 V |
Output operation voltage (min) | 200 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 1335 J |
EMI/RFI noise filtering | Yes |
Emergency Power Off (EPO) | Yes |
Waveform | Pure sine |
Power protection features | Overload |
Output voltage Total Harmonic Distortion (THD) | 3% |
Output power factor | 1 |
Input power factor | 0.99 |
Input current Total Harmonic Distortion (THD) | 1.5% |
Crest factor | 3:1 |
Noise level | 62 dB |
Audible alarm(s) | Yes |
Efficiency (ECO mode) | 98% |
ECO mode | Yes |
Input frequency | 50/60 Hz |
Carrying handle(s) | No |
Heat dissipation | 2047 BTU/h |
Package type | Box |
Compatibility | BPS240V9ART3U |
Charging current | 4 A |
Ports & interfaces |
---|
USB port | Yes |
AC outlets quantity | 9 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler, Terminal |
Power plug | C13 coupler |
RS-232 ports | 1 |
Battery |
---|
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 4 h |
Typical backup time at half load | 11.2 min |
Typical backup time at full load | 2.9 min |
Hot-swap battery | Yes |
Charging current | 4 A |
Design |
---|
Rack capacity | 5U |
Form factor | Tower |
Compatibility | BPS240V9ART3U |
Product colour | Black |
Built-in fan | Yes |
Housing material | Metal |
Display type | LCD |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 1500 m |
Non-operating altitude | 0 - 1500 m |
Technical details |
---|
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Sustainability certificates | CE, RoHS |
Cooling |
---|
Built-in fan | Yes |
Weight & dimensions |
---|
Package type | Box |
Width | 433 mm |
Depth | 661 mm |
Height | 213.5 mm |
Weight | 80 kg |
Package width | 575 mm |
Package depth | 890 mm |
Package height | 489 mm |
Package weight | 99 kg |
Packaging data |
---|
Cables included | USB cable |
Manual | Yes |
Package type | Box |
Package width | 575 mm |
Package depth | 890 mm |
Package height | 489 mm |
Package weight | 99 kg |
Packaging content |
---|
Cables included | USB cable |
Manual | Yes |
