Power |
---|
Output frequency | 50/60 Hz |
Output power capacity | 2 kVA |
Output power | 1800 W |
Input operation voltage (min) | 110 V |
Input operation voltage (max) | 300 V |
Output operation voltage (max) | 230 V |
Surge energy rating | 945 J |
Efficiency | 90% |
Emergency Power Off (EPO) | Yes |
Crest factor | 3:1 |
ECO mode | Yes |
Input frequency | 40/70 Hz |
Performance |
---|
Audible alarm modes | Low battery alarm, Overload alarm |
UPS topology | Double-conversion (Online) |
Waveform | Sine |
Noise level | 50 dB |
Audible alarm(s) | Yes |
Features |
---|
Output frequency | 50/60 Hz |
Audible alarm modes | Low battery alarm, Overload alarm |
UPS topology | Double-conversion (Online) |
Output power capacity | 2 kVA |
Output power | 1800 W |
Input operation voltage (min) | 110 V |
Input operation voltage (max) | 300 V |
Output operation voltage (max) | 230 V |
Surge energy rating | 945 J |
Efficiency | 90% |
Emergency Power Off (EPO) | Yes |
Waveform | Sine |
Crest factor | 3:1 |
Noise level | 50 dB |
Audible alarm(s) | Yes |
ECO mode | Yes |
Input frequency | 40/70 Hz |
Power source type | AC |
Detachable power cord | Yes |
Ports & interfaces |
---|
USB port | Yes |
AC outlets quantity | 7 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
RS-232 ports | 1 |
Modem (RJ-11) ports | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Battery |
---|
Battery life (max) | 10 year(s) |
Battery technology | Lithium-Ion (Li-Ion) |
Battery recharge time | 4.8 h |
Typical backup time at half load | 88 min |
Typical backup time at full load | 45 min |
Battery voltage | 48 V |
Design |
---|
Rack capacity | 4U |
Form factor | Rackmount/Tower |
Product colour | Black |
International Protection (IP) code | IP20 |
Certification | CB , CE, EAC, IEC 62619, KC, RCM, TISI, UKCA, UN 38.3, RoHS |
Cooling type | Active |
Built-in fan | Yes |
Control type | Buttons |
Display type | LCD |
Operational conditions |
---|
Storage temperature (T-T) | -20 - 50 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Non-operating altitude | 0 - 15000 m |
Technical details |
---|
Output frequency | 50/60 Hz |
Sustainability certificates | CE, RoHS, UKCA |
Cooling |
---|
Cooling type | Active |
Built-in fan | Yes |
Weight & dimensions |
---|
Width | 438 mm |
Depth | 616 mm |
Height | 172 mm |
Weight | 38.3 kg |
Package width | 800 mm |
Package depth | 600 mm |
Package height | 480 mm |
Package weight | 50.6 kg |
Packaging data |
---|
Cables included | Phone (RJ-11), Power load cable, RJ-45, RS-232, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Package width | 800 mm |
Package depth | 600 mm |
Package height | 480 mm |
Package weight | 50.6 kg |
Certificates |
---|
Certification | CB , CE, EAC, IEC 62619, KC, RCM, TISI, UKCA, UN 38.3, RoHS |
Packaging content |
---|
Cables included | Phone (RJ-11), Power load cable, RJ-45, RS-232, USB cable |
Rack mount kit | Yes |
Manual | Yes |
