| Power |
|---|
| Output frequency | 50/60 Hz |
| Output power capacity | 2.2 kVA |
| Output power | 1980 W |
| Input operation voltage (min) | 151 V |
| Input operation voltage (max) | 302 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 375 J |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Input frequency | 50/60 Hz |
| Ports & interfaces |
|---|
| Cable length | 2 m |
| USB port | Yes |
| Serial interface | Yes |
| Serial interface type | RJ-45 |
| SmartSlot | Yes |
| AC outlets quantity | 10 AC outlet(s) |
| AC outlet types | C13 coupler, C19 coupler |
| Number of output IEC jumpers | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance |
|---|
| UPS topology | Line-Interactive |
| Number of output phases | 1 |
| Number of input phases | 1 |
| Response time | 6 ms |
| Waveform | Sine |
| Auto-restart | Yes |
| Automatic Voltage Regulation (AVR) | Yes |
| Noise level | 55 dB |
| LED indicators | Yes |
| Audible alarm(s) | Yes |
| Features |
|---|
| Output frequency | 50/60 Hz |
| UPS topology | Line-Interactive |
| Output power capacity | 2.2 kVA |
| Number of output phases | 1 |
| Number of input phases | 1 |
| Response time | 6 ms |
| Output power | 1980 W |
| Input operation voltage (min) | 151 V |
| Input operation voltage (max) | 302 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 375 J |
| Waveform | Sine |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Auto-restart | Yes |
| Automatic Voltage Regulation (AVR) | Yes |
| Noise level | 55 dB |
| Audible alarm(s) | Yes |
| Input frequency | 50/60 Hz |
| Power source type | AC |
| Heat dissipation | 215 BTU/h |
| Battery |
|---|
| Battery life (max) | 5 year(s) |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 3 h |
| Hot-swap battery | Yes |
| Cold start | Yes |
| Automatic battery test | Yes |
| Design |
|---|
| Rack capacity | 2U |
| Form factor | Rackmount/Tower |
| Product colour | Black, Grey |
| Certification | IRAM, RCM |
| Cable length | 2 m |
| LED indicators | Yes |
| Display type | LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 15240 m |
| Technical details |
|---|
| Output frequency | 50/60 Hz |
| Sustainability compliance | Yes |
| Sustainability certificates | CE, GS mark, RoHS, VDE |
| Weight & dimensions |
|---|
| Width | 432 mm |
| Depth | 683 mm |
| Height | 86 mm |
| Weight | 42.3 kg |
| Package width | 980 mm |
| Package depth | 600 mm |
| Package height | 254 mm |
| Package weight | 49.7 kg |
| Packaging data |
|---|
| Cables included | USB cable |
| Rack mount kit | Yes |
| Package width | 980 mm |
| Package depth | 600 mm |
| Package height | 254 mm |
| Package weight | 49.7 kg |
| Certificates |
|---|
| Certification | IRAM, RCM |
| Other features |
|---|
| Input connection type | BS1363A British, IEC 320 C20, Schuko CEE 7 / EU1-16P |
| Nominal output voltage | 230 V |
| Nominal input voltage | 230 V |
| Packaging content |
|---|
| Cables included | USB cable |
| Rack mount kit | Yes |
