All stock codes associated to this product
65TR3DK-B, 65TR3DKB, LG65TR3DKB, LG-65TR3DK-B, 0195174042649
Display |
---|
Display diagonal | 165.1 cm (65") |
Contrast ratio (typical) | 1200:1 |
Touchscreen | Yes |
Touchscreen type | Infrared |
Number of simultaneous touchpoints | 40 |
Panel type | IPS |
Viewing angle, vertical | 178 ° |
Viewing angle, horizontal | 178 ° |
Response time | 8 ms |
Colour gamut | 72% |
Touch technology | Multi-touch |
Display brightness | 390 cd/m ² |
Display resolution | 3840 x 2160 pixels |
HD type | 4K Ultra HD |
Contrast ratio (dynamic) | 50000:1 |
Maximum refresh rate | 60 Hz |
Native aspect ratio | 16:9 |
Features |
---|
Display diagonal | 165.1 cm (65") |
Contrast ratio (typical) | 1200:1 |
Touchscreen | Yes |
Touchscreen type | Infrared |
Number of simultaneous touchpoints | 40 |
Panel type | IPS |
Viewing angle, vertical | 178 ° |
Viewing angle, horizontal | 178 ° |
Response time | 8 ms |
Colour gamut | 72% |
Touch technology | Multi-touch |
Display brightness | 390 cd/m ² |
Display resolution | 3840 x 2160 pixels |
HD type | 4K Ultra HD |
Contrast ratio (dynamic) | 50000:1 |
Maximum refresh rate | 60 Hz |
Native aspect ratio | 16:9 |
Product colour | Black |
Graphics card | Mali-G52 MP2 |
Operating system installed | Android 11 |
Computer system |
---|
Graphics card | Mali-G52 MP2 |
Operating system installed | Android 11 |
Maximum internal memory | 32 GB |
Built-in processor | Yes |
Processor cores | 4 |
RAM capacity | 4 GB |
Processor architecture | ARM Cortex-A55 |
Audio |
---|
Built-in speaker(s) | Yes |
Number of built-in speakers | 2 |
Speaker power | 15 W |
Network |
---|
Bluetooth | Yes |
Bluetooth version | 5.0 |
Wi-Fi | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ethernet LAN | Yes |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
Ports & interfaces |
---|
USB 2.0 ports quantity | 1 |
USB connector type | USB Type-A, USB Type-B, USB Type-C |
HDMI ports quantity | 4 |
HDCP | Yes |
Ethernet LAN (RJ-45) ports | 2 |
RS-232 ports | 1 |
USB Type-C ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 4 |
USB 2.0 Type-B Touch ports quantity | 2 |
HDMI output ports quantity | 1 |
S/PDIF out port | Yes |
HDCP version | 2.2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
VGA (D-Sub) ports quantity | 1 |
Line-in | Yes |
Line-out | Yes |
USB Power Delivery | Yes |
OPS slot | 1 |
Bluetooth | Yes |
Bluetooth version | 5.0 |
Wi-Fi | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ethernet LAN | Yes |
Ergonomics |
---|
Product colour | Black |
Panel mounting interface | 600 x 400 mm |
VESA mounting | Yes |
Power |
---|
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power consumption (typical) | 220 W |
Power consumption (standby) | 0.5 W |
Power consumption (max) | 420 W |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Technical details |
---|
Touchscreen | Yes |
Panel type | IPS |
Viewing angle, vertical | 178 ° |
Viewing angle, horizontal | 178 ° |
Response time | 8 ms |
Colour gamut | 72% |
Quantity per pack | 1 pc(s) |
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR |
Weight & dimensions |
---|
Width | 1489 mm |
Depth | 88 mm |
Height | 897 mm |
Weight | 35 kg |
Packaging data |
---|
Package width | 1628 mm |
Package depth | 208 mm |
Package height | 1005 mm |
Package weight | 44.7 kg |
Quantity per pack | 1 pc(s) |
Projector |
---|
Contrast ratio (typical) | 1200:1 |
Processor |
---|
Built-in processor | Yes |
Processor cores | 4 |
Processor architecture | ARM Cortex-A55 |
Sustainability |
---|
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR |
Memory |
---|
Maximum internal memory | 32 GB |
RAM capacity | 4 GB |
Colour |
---|
Product colour | Black |
Various Teaching TemplatesTR3DK series offers a variety of educational templates and teaching tools such as a ruler, table, and sticky notes, allowing for active engagement by students and enabling intuitive classes. Editing images and videos becomes easy with TR3DK series, and created resources can be easily shared with others through QR codes.
Multi-touchTR3DK Digital Board can simultaneously detect up to 40 points for multi-touch functionality. This creates a lifelike board touch experience, helping students easily become accustomed and truly engage in classes. This leads to the maximum concentration and organic engagement of students.
Easy to Save / Import / ExportTR3DK series include simple import and export functionality. Resources can be saved and imported directly to and from Google Drive or OneDrive, and files can be imported from a USB drive (Users can browse resources saved on USB storage).
Wireless ScreenShareLG CreateBoard Share enables users to show up to 9 shared screens or a file on a screen in real-time when the LG CreateBoard Share app is installed on the device. Also, files from the host can be easily sent to any devices connected to the LG CreateBoard Share app, and several quick controls by the host are available.
LG ConnectedCare DMSLG ConnectedCare DMS is a cloud solution for remotely monitoring, controlling, and managing the status of TR3DK Digital Board installed in educational environments. This feature enables IT managers to operate and manage important resources on operating devices without physically visiting sites.
Bluetooth ConnectivityTR3DK Digital Board supports wireless Bluetooth connections to various devices such as a speaker, mouse, keyboard, etc. This is optimal for building a hybrid environment so that online and offline classes can proceed smoothly.
C-type ConnectionUSB-C connectivity simplifies connections which enables charging and sending data simultaneously over just one single cable.
QR Login for
Easy Cloud AccessThe QR code on the home screen reduces preparation time for class by enabling personal device verification. Users can sign up for a variety of apps on the TR3DK Digital Board including Google Drive and OneDrive with just one QR verification without any additional login process. Once a lesson is finished, users can simply click the Logout button to disconnect, thus the risk of a personal information leak is reduced.
Advanced Eye-CareTR3DK Digital Board has introduced a flicker-free function. With the reduced flickering of the monitor's backlight, users can use the device with more comfort even when using it for a long time.
Front Connectivity DesignTR3DK Digital Board features front display ports and speakers which are ideal for both teachers and students, enabling content to be delivered easier with more immersive sound.
Built-in OPS SlotTR3DK Digital Board supports OPS slots, allowing you to easily and conveniently mount OPS desktop at the back of the TR3DK Digital Board without the hassle of connecting to an external desktop, offering you more expanded functions.
Smart ViewingThe Smart Viewing feature of TR3DK Digital Board enables efficient teaching. Two or more materials can be displayed on the same screen simultaneously without having to repeat Alt-tab, making teaching more convenient and efficient. Two materials can be displayed side by side (multi window mode), or one material can be overlaid on the other one (picture-in-picture mode).
Power SavingWhen a device doesn’t receive an external input signal for a specific amount of time set by the user, the device goes into standby mode. Devices can also be automatically turned on or off at specific time or day set by the user, which contributes to save energy.
