All stock codes associated to this product
VIGI C340S(4MM), VIGIC340S(4MM), VIGI-C340S(4MM), VIGIC340S(4mm), VIGI C340S(4mm), NWTLVIGIC340S4, NWTL-VIGI-C340S-4, 4895252500790
| Performance |
|---|
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Day/night mode | Yes |
| Dynamic range | 120 dB |
| Design |
|---|
| Form factor | Box |
| Product colour | White |
| Mounting type | Wall |
| International Protection (IP) code | IP67 |
| Housing material | Metal, Plastic |
| Camera |
|---|
| Minimum illumination | 0.0005 lx |
| Tilt angle range | -90 - 90 ° |
| Pan range | -90 - 90 ° |
| Camera shutter speed | 1/10000 s |
| Lens viewing angle, horizontal | 95.2 ° |
| Lens viewing angle, vertical | 50.6 ° |
| Lens viewing angle, diagonal | 114.7 ° |
| Number of Privacy masking areas | 4 |
| Image sensor |
|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Lens system |
|---|
| Number of lenses | 1 |
| Maximum aperture number | 1 |
| Detect distance | 70 m |
| Observe distance | 29 m |
| Recognize distance | 14 m |
| Identify distance | 7 m |
| Minimum aperture number | 1 |
| Focal length range | 4 mm |
| Fixed focal length | 4 mm |
| Night vision |
|---|
| Number of illumination LEDs | 5 |
| Video |
|---|
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Maximum resolution | 2988 x 1520 pixels |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2550 x 1440, 2688 x 1520 |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Frame rate | 60 fps |
| Total megapixels | 4 MP |
| Audio |
|---|
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Sample rate | 8 kHz |
| Built-in speaker(s) | Yes |
| Built-in microphone | Yes |
| Bit rate range | 64 - 64 Kbit/s |
| Network |
|---|
| Ethernet LAN | Yes |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Privacy protection | Yes |
| IP address filtering | Yes |
| Password protection | Yes |
| Digest authentication | Yes |
| Power |
|---|
| Power source type | DC |
| Power consumption (max) | 10.1 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions |
|---|
| Width | 102 mm |
| Depth | 236 mm |
| Height | 99 mm |
| Packaging content |
|---|
| Number of cameras | 1 |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+ |
VIGI ColorPro Night Vision
VIGI’s industry-leading ColorPro Night Vision technology enables its cameras to pierce the night and see everything in fine detail.
By adopting this best-in-class technology, VIGI C340S can provide 4MP high resolution and capture more vivid full-color images
in extreme low-light conditions.
Better than the Naked Eye
Featuring high low-light sensitivity, VIGI’s ColorPro Night Vision produces unparalleled colors along with amazingly crisp images in
ultra-low light conditions, which can’t be achieved with natural eyesight.
Beyond IR, Beyond Full-Color
Images captured by IR cameras or traditional full-color cameras will suffer from digital noise and the loss of detail. VIGI’s ColorPro Night
Vision cameras reveal excellent image details even in extreme darkness.
Less Light Pollution
Bright illumination is required by conventional full-color cameras to capture images at pitch-dark hours. But VIGI's ColorPro Night Vision cameras
delivers true color and bright imaging even in extremely low light with no spotlights needed, greatly reducing environmental light pollution.
Human & Vehicle Classification
Integrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.
Comprehensive AI Detection with Pre-Set Rules Supported
By setting the detection rules in advance, VIGI AI-powered cameras can accurately capture various abnormal events. This will greatly reduce false alarms and cover your specified monitoring needs in different scenarios.
Face Recognition
VIGI’s advanced built-in face recognition algorithm enables cameras to intelligently capture faces, extract facial features, and form unique facial data. By comparing the facial data with a face library, quickly match a human face, efficiently reducing the risk of unauthorized access.
People & Vehicle Analytics
Quickly find people and vehicles of interest using a series of attributes.
People Analytics
Filter people of interest by various attributes, such as gender, hair length, and clothing, allowing you to improve search efficiency.
Vehicle Analytics
Identify and search for vehicles of interest based on vehicle color and type for targeting meaningful events in a short time.
Active DefenseWarn potential intruders instantly with sound and light when abnormal events are detected.
Two-Way Audio
With voice intercom support, carry two-way conversations while watching your feed from anywhere.
PoE & IP67
Outdoor PoE connection makes your wiring remarkably easy. Reliable IP67 enables stable outdoor performance.
One system. Full security.
Run your business with peace of mind.
The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build – whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
