All stock codes associated to this product
VIGI C540-4G(4mm), VIGI C5404G(4mm), VIGI C5404G(4MM), VIGI C540-4G(4MM), VIGIC5404G(4MM), VIGI-C540-4G(4MM), NWTLVIGIC5404G4, NWTL-VIGI-C540-4G-4, TL80031, 4895252504910
| Performance |
|---|
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Certification | RCM, BSMI, VCCI, NTRA, KC |
| Design |
|---|
| Form factor | Turret |
| Product colour | Black, White |
| Mounting type | Ceiling/wall |
| International Protection (IP) code | IP66 |
| Housing material | Plastic |
| Camera |
|---|
| Tilt angle range | 0 - 120 ° |
| Pan range | 0 - 350 ° |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, horizontal | 79 ° |
| Lens viewing angle, vertical | 43 ° |
| Lens viewing angle, diagonal | 93 ° |
| Image sensor |
|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 3.06 mm (1 / 3.06") |
| Lens system |
|---|
| Number of lenses | 1 |
| Zoom capability | Yes |
| Lens diameter | 4 mm |
| Night vision |
|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
| Video |
|---|
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Mirror, Saturation, Sharpness |
| Privacy masking | Yes |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Bit rate | 256 Kbps - 4 Mbps |
| Noise reduction technology | 3D noise reduction |
| Maximum resolution | 2560 x 1440 pixels |
| Supported graphics resolutions | 320 x 240, 352 x 288, 640 x 480 (VGA), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440 |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 4 MP |
| Audio |
|---|
| Built-in speaker(s) | Yes |
| Built-in microphone | Yes |
| Network |
|---|
| 4G standard | LTE-TDD & LTE-FDD |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| SIM card slot | Yes |
| Number of simultaneous live view channels | 3 channels |
| Live view | Yes |
| SIM card type | NanoSIM |
| Storage |
|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Built-in HDD | No |
| Maximum memory card size | 256 GB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Intelligent Video Surveillance (IVS) system features | Human detection |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Mirror | Yes |
| Digest authentication | Yes |
| Management features |
|---|
| Reset button | Yes |
| Behavior analysis | Intrusion detection, Line crossing detection |
| Power |
|---|
| Power source type | PoE |
| Power consumption (Power over Ethernet (PoE)) | 14 W |
| DC output voltage | 12 |
| Certificates |
|---|
| Certification | RCM, BSMI, VCCI, NTRA, KC |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Weight & dimensions |
|---|
| Width | 120 mm |
| Depth | 172 mm |
| Height | 198 mm |
| Package width | 163 mm |
| Package depth | 213 mm |
| Package height | 243 mm |
| Package weight | 950 g |
| Features |
|---|
| Basic event | Motion Detection, Camera Tampering Detection, Exception |
| Packaging content |
|---|
| Number of cameras | 1 |
| Mounting kit | Yes |
| Technical details |
|---|
| Sustainability certificates | CE, RoHS |
| Other features |
|---|
| Video compression formats | H.264, H.264+, H.265, H.265+ |
Clarity and Colors, All in One
Experience clear, vibrant 24-hour monitoring, even in total darkness, with the VIGI Full-Color camera. Its 4MP resolution, large-aperture
lens, high-sensitivity sensor, and supplemental lights deliver comprehensive, colorful surveillance.
Network Anywhere You Need It
No need to connect network cables. Just insert a Nano-SIM card, then your camera is ready to connect to a 4G LTE network. Enjoy hassle-free installation and simple monitoring in places where the internet is not available, such as farms, forests, and construction sites.
Powerful Pan Tilt
Cover every corner flexibly with VIGI’s Pan Tilt camera. Customized patrol routes provide more intelligent and quick options to monitor key areas (up to 8 points for each route), reducing manual costs for adjusting pan & tilt angles repeatedly.
Human & Vehicle Classification
Integrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.
Automatic Tracking
Automatically tracks persons or vehicles of interest and provides seamless and longer video. This way, you will better understand what's happening and take action without wasting time on irrelevant footage.
Smart Detection for Efficient Monitoring
By setting the detection rules in advance, VIGI AI-powered cameras can accurately capture various abnormal events. This will greatly reduce false alarms and cover your specified monitoring needs in different scenarios.
Active Defense
Warn potential intruders off instantly with sound and light to pro-actively protect your property, even while away from the scene.
Two-Way Audio
With voice intercom support, carry two-way conversations while watching your feed from anywhere.
Smart Video Coding by H.265+
Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
Remote Management
Take full control over your security anytime and anywhere on the VIGI app or client.
One system. Full security.
Run your business with peace of mind.
The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build – whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
