LH85QMCEBGCXXY | Samsung LH85QMCEBGC Digital signage flat panel 2.16 m (85")

Display
Display diagonal	2.16 m (85")
Display resolution	3840 x 2160 pixels
Display brightness	500 cd/m Â²
HD type	4K Ultra HD
Response time	10 ms
Contrast ratio (typical)	4000:1
Viewing angle, horizontal	178 Â°
Viewing angle, vertical	178 Â°
Pixel pitch	0.487 x 0.487 mm
Vertical scan range	48 - 75 Hz
Touchscreen	No
Panel type	VA
Horizontal scan range	30 - 81 kHz
Display technology	LED
Ports & interfaces
Remote (IR) input	1
Ethernet LAN	Yes
HDMI ports quantity	3
USB port	Yes
HDMI version	2.0
DVI port	No
Ethernet LAN (RJ-45) ports	1
RS-232 interface	Yes
Wi-Fi	Yes
USB ports quantity	2
PC Audio out	Yes
DisplayPorts quantity	1
DisplayPorts in	1
HDMI input ports quantity	3
Audio
Built-in speaker(s)	No
Design
Product design	Digital signage flat panel
Product colour	Black
Placement supported	Indoor
Panel mounting interface	600 x 400 mm
Bezel width (top)	1.39 cm
Bezel width (side)	1.39 cm
Bezel width (bottom)	1.39 cm
Certification	EMC Class A Safety 60950-1, 62368-1
VESA mounting	Yes
Mounting type	Wall
Wall mountable	Yes
Performance
Purpose	Universal
Operating hours (hours/days)	24/7
HDCP	Yes
HDCP version	2.2
Wi-Fi	Yes
Power
Power consumption (typical)	330 W
AC input voltage	220-240 V
AC input frequency	50/60 Hz
Power consumption (sleep)	0.5 W
Computer system
Computer system	No
Operating system installed	Tizen
Built-in processor	No
Operating system version	7.0
Weight & dimensions
Display width	1904.3 mm
Display depth	28.5 mm
Display height	1085.3 mm
Display weight	41.9 kg
Packaging data
Package width	1222 mm
Package depth	210 mm
Package height	2077 mm
Package weight	53.9 kg
Operational conditions
Operating temperature (T-T)	0 - 40  Â°C
Operating relative humidity (H-H)	10 - 80%
Certificates
Certification	EMC Class A Safety 60950-1, 62368-1
Technical details
VESA mounting	Yes
Panel type	VA
DisplayPorts in	1
Thin Client
Operating system installed	Tizen
Features
Wall mountable	Yes
Other features
Wi-Fi	Yes
PC Audio out	Yes
Panel type	VA
DisplayPorts in	1
Display technology	LED
Bezel width (top)	1.39 cm
Bezel width (side)	1.39 cm
Bezel width (bottom)	1.39 cm

---

Slim design. Stunning performance.
Introducing QMC, the slimmest display in Samsung’s Professional Display range. It brings elegance to business while maximising space. With built-in solutions and intuitive home screen UX, the QMC is easy to use and helps enable businesses in various verticals to achieve growth with its efficiency and design innovation.


Maximum impact in minimum space
Ultra Slim Depth
The QMC's ultra-slim thickness of 28.5mm makes it the thinnest option in Samsung’s UHD 4K series. Its sleek design and Slim Fit Wall Mount, helps you optimise space and install it neatly in a wide range of business environments.


Clean visuals in landscape or portrait mode
Even Bezel
The QMC’s bezels are consistent and even on all four sides of the display, with the same thickness and dimensions. The new even bezel design helps prevent visual issues from arising when the display is adjusted to portrait mode.


Secure and even mounting
Centred VESA Holes
The central positioning of the VESA holes on the back of the display helps evenly distribute its weight for secure mounting. With the VESA holes positioned in the centre, this helps prevent the display from tilting unintentionally when adjusted into portrait mode.


Lifelike colour expression
Dynamic Crystal Colour
The QMC series features Dynamic Crystal Display, using 10 bit processing for vivid colour expression, allowing viewers to enjoy a wide spectrum of colours.


View lifelike shades of colour in powerful 4K
Quantum Processor Lite 4K
Intelligent UHD upscaling technology, made possible by Samsung’s Crystal Processor 4K, enables content developed at a lower resolution to be elevated to UHD-level quality. It also performs edge restoration and noise reduction to help optimise on-screen text and imagery.


Clear visibility
Non-Glare
The QMC features non-glare panels that help provide visibility across a variety of environments. This helps allow businesses to deliver accurate information in various ambient lighting conditions.


Connect with convenience
Home User Interface (UI)
The QMC series’ home screen UI displays popular categories like Favourites, Sources and Settings on the same screen for convenience. The Favourites folder grants users quick, easy access to frequently used features.


Collaborate between screens with wire-free speed
Smartview+
SmartView+ enables wireless screen sharing without cable connections to assist with easy collaboration. Users can now enable the screen sharing functionality at the start of a meeting, allowing the meeting admin to quickly switch between screens with one click.


Streamlined calibration between screens with mobile app
Smart Calibration
Maintain brand consistency across every display in every location. Using the Samsung mobile app, Smart Calibration helps ensure every display is calibrated correctly, showcasing brand logos and other collateral in the exact colours required.


Enhance professional environments with expert tools
Professional Modes
Built-in professional modes enable more possibilities in specific verticals. Director Mode minimises post-processing enhancements, helping to align content to the director’s original intention. Medical teams can simulate medical images such as X-rays with DICOM Simulation Mode, meeting DICOM's full greyscale standards.


Smooth and virtually seamless content playback
MagicINFO S10 Player
The embedded MagicINFO™ S10 player, backed by the powerful Tizen operating system, helps boost the overall performance of the display and offers painless management. This helps ensure seamless transitions and playback to deliver a better experience for both customers and store managers.


Everyday Sustainability
Energy Star, EPEAT and TÜV Rheinland Carbon Footprint Certification
Samsung is making diverse efforts to reduce our environmental impact in smart display, and encouraging users to pursue a more sustainable life. The QMC series has earned a series of certifications for environmentally preferable products from highly recognised institutes in Germany and the U.S.
