Power |
---|
Output frequency | 50/60 Hz |
Output power capacity | 2 kVA |
Output power | 1600 W |
Input operation voltage (min) | 110 V |
Input operation voltage (max) | 285 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 600 J |
Efficiency | 88% |
Output voltage Total Harmonic Distortion (THD) | 3% |
Crest factor | 3:1 |
Input frequency | 40/70 Hz |
Performance |
---|
UPS topology | Double-conversion (Online) |
Waveform | Sine |
Noise level | 50 dB |
Audible alarm(s) | Yes |
Features |
---|
Output frequency | 50/60 Hz |
UPS topology | Double-conversion (Online) |
Output power capacity | 2 kVA |
Output power | 1600 W |
Input operation voltage (min) | 110 V |
Input operation voltage (max) | 285 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 600 J |
Efficiency | 88% |
Waveform | Sine |
Output voltage Total Harmonic Distortion (THD) | 3% |
Crest factor | 3:1 |
Noise level | 50 dB |
Audible alarm(s) | Yes |
Input frequency | 40/70 Hz |
Ports & interfaces |
---|
AC outlets quantity | 4 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
Battery |
---|
Battery voltage | 72 V |
Design |
---|
Rack capacity | 2U |
Form factor | Rackmount |
Product colour | Black |
International Protection (IP) code | IP20 |
Certification | UKCA EAC TISI EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
Cooling type | Active |
Display type | LCD |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -20 - 50 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details |
---|
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Sustainability certificates | CE, REACH, RoHS, WEEE |
Doesn't contain | Mercury |
Cooling |
---|
Cooling type | Active |
Weight & dimensions |
---|
Width | 438 mm |
Depth | 462 mm |
Height | 86 mm |
Weight | 9.2 kg |
Package width | 545 mm |
Package depth | 700 mm |
Package height | 240 mm |
Package weight | 18.4 kg |
Packaging data |
---|
Cables included | Output power cable, RS-232, USB cable |
Package width | 545 mm |
Package depth | 700 mm |
Package height | 240 mm |
Package weight | 18.4 kg |
Certificates |
---|
Certification | UKCA EAC TISI EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
Packaging content |
---|
Cables included | Output power cable, RS-232, USB cable |
