All stock codes associated to this product
LH55QMCEBGCXXY, 8806094981858
| Display |
|---|
| Display diagonal | 139.7 cm (55") |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m ² |
| HD type | 4K Ultra HD |
| Response time | 10 ms |
| Contrast ratio (typical) | 4000:1 |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
| Pixel pitch | 0.315 x 0.315 mm |
| Vertical scan range | 48 - 75 Hz |
| Touchscreen | No |
| Panel type | VA |
| Horizontal scan range | 30 - 81 kHz |
| Display technology | LED |
| Haze rate | 25% |
| Ports & interfaces |
|---|
| Remote (IR) input | 1 |
| Ethernet LAN | Yes |
| HDMI ports quantity | 3 |
| USB port | Yes |
| HDMI version | 2.0 |
| DVI port | No |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 interface | Yes |
| Wi-Fi | Yes |
| USB ports quantity | 2 |
| PC Audio out | Yes |
| DisplayPorts quantity | 1 |
| DisplayPorts in | 1 |
| HDMI input ports quantity | 3 |
| Audio |
|---|
| Built-in speaker(s) | No |
| Design |
|---|
| Product design | Digital signage flat panel |
| Product colour | Black |
| Placement supported | Indoor |
| Panel mounting interface | 200 x 200 mm |
| Bezel width (top) | 1.15 cm |
| Bezel width (side) | 1.15 cm |
| Bezel width (bottom) | 1.15 cm |
| Certification | EMC Class A Safety 60950-1, 62368-1 |
| VESA mounting | Yes |
| Mounting type | Wall |
| Wall mountable | Yes |
| Performance |
|---|
| Purpose | Universal |
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| HDCP version | 2.2 |
| Wi-Fi | Yes |
| Power |
|---|
| Power consumption (typical) | 154 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (sleep) | 0.5 W |
| Computer system |
|---|
| Computer system | No |
| Operating system installed | Tizen |
| Built-in processor | No |
| Operating system version | 7.0 |
| Weight & dimensions |
|---|
| Display width | 1237.9 mm |
| Display depth | 28.5 mm |
| Display height | 708.8 mm |
| Display weight | 15.7 kg |
| Packaging data |
|---|
| Package width | 835 mm |
| Package depth | 148 mm |
| Package height | 1403 mm |
| Package weight | 19.9 kg |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Certificates |
|---|
| Certification | EMC Class A Safety 60950-1, 62368-1 |
| Technical details |
|---|
| VESA mounting | Yes |
| Panel type | VA |
| DisplayPorts in | 1 |
| Thin Client |
|---|
| Operating system installed | Tizen |
| Features |
|---|
| Wall mountable | Yes |
| Other features |
|---|
| Wi-Fi | Yes |
| PC Audio out | Yes |
| Panel type | VA |
| DisplayPorts in | 1 |
| Display technology | LED |
| Bezel width (top) | 1.15 cm |
| Bezel width (side) | 1.15 cm |
| Bezel width (bottom) | 1.15 cm |
Slim design. Stunning performance.Introducing QMC, the slimmest display in Samsung’s Professional Display range. It brings elegance to business while maximising space. With built-in solutions and intuitive home screen UX, the QMC is easy to use and helps enable businesses in various verticals to achieve growth with its efficiency and design innovation.
Maximum impact in minimum space
Ultra Slim DepthThe QMC's ultra-slim thickness of 28.5mm makes it the thinnest option in Samsung’s UHD 4K series. Its sleek design and Slim Fit Wall Mount, helps you optimise space and install it neatly in a wide range of business environments.
Clean visuals in landscape or portrait mode
Even BezelThe QMC’s bezels are consistent and even on all four sides of the display, with the same thickness and dimensions. The new even bezel design helps prevent visual issues from arising when the display is adjusted to portrait mode.
Secure and even mounting
Centred VESA Holes The central positioning of the VESA holes on the back of the display helps evenly distribute its weight for secure mounting. With the VESA holes positioned in the centre, this helps prevent the display from tilting unintentionally when adjusted into portrait mode.
Lifelike colour expression
Dynamic Crystal ColourThe QMC series features Dynamic Crystal Display, using 10 bit processing for vivid colour expression, allowing viewers to enjoy a wide spectrum of colours.
View lifelike shades of colour in powerful 4K
Quantum Processor Lite 4K Intelligent UHD upscaling technology, made possible by Samsung’s Crystal Processor 4K, enables content developed at a lower resolution to be elevated to UHD-level quality. It also performs edge restoration and noise reduction to help optimise on-screen text and imagery.
Clear visibility
Non-GlareThe QMC features non-glare panels that help provide visibility across a variety of environments. This helps allow businesses to deliver accurate information in various ambient lighting conditions.
Connect with convenience
Home User Interface (UI)The QMC series’ home screen UI displays popular categories like Favourites, Sources and Settings on the same screen for convenience. The Favourites folder grants users quick, easy access to frequently used features.
Collaborate between screens with wire-free speed
Smartview+ SmartView+ enables wireless screen sharing without cable connections to assist with easy collaboration. Users can now enable the screen sharing functionality at the start of a meeting, allowing the meeting admin to quickly switch between screens with one click.
Streamlined calibration between screens with mobile app
Smart Calibration Maintain brand consistency across every display in every location. Using the Samsung mobile app, Smart Calibration helps ensure every display is calibrated correctly, showcasing brand logos and other collateral in the exact colours required.
Enhance professional environments with expert tools
Professional ModesBuilt-in professional modes enable more possibilities in specific verticals. Director Mode minimises post-processing enhancements, helping to align content to the director’s original intention. Medical teams can simulate medical images such as X-rays with DICOM Simulation Mode, meeting DICOM's full greyscale standards.
Smooth and virtually seamless content playback
MagicINFO S10 Player The embedded MagicINFO™ S10 player, backed by the powerful Tizen operating system, helps boost the overall performance of the display and offers painless management. This helps ensure seamless transitions and playback to deliver a better experience for both customers and store managers.
Everyday Sustainability
Energy Star, EPEAT and TÜV Rheinland Carbon Footprint CertificationSamsung is making diverse efforts to reduce our environmental impact in smart display, and encouraging users to pursue a more sustainable life. The QMC series has earned a series of certifications for environmentally preferable products from highly recognised institutes in Germany and the U.S.
