Power |
---|
Output frequency | 50/60 Hz |
Output power capacity | 1.35 kVA |
Output power | 780 W |
Input operation voltage (min) | 165 V |
Input operation voltage (max) | 265 V |
Maximum current | 10 A |
Efficiency | 98.5% |
Input frequency | 50/60 Hz |
Performance |
---|
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Digital Subscriber Line (DSL), Fax, Modem, Network, Telephone |
Waveform | Pure sine |
Power protection features | Overload |
Auto-restart | Yes |
Automatic Voltage Regulation (AVR) | Yes |
Noise level | 35 dB |
LED indicators | Yes |
Audible alarm(s) | Yes |
Features |
---|
Output frequency | 50/60 Hz |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Output power capacity | 1.35 kVA |
Output power | 780 W |
Input operation voltage (min) | 165 V |
Input operation voltage (max) | 265 V |
Maximum current | 10 A |
Efficiency | 98.5% |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Digital Subscriber Line (DSL), Fax, Modem, Network, Telephone |
Waveform | Pure sine |
Power protection features | Overload |
Auto-restart | Yes |
Automatic Voltage Regulation (AVR) | Yes |
Noise level | 35 dB |
Audible alarm(s) | Yes |
Input frequency | 50/60 Hz |
Ports & interfaces |
---|
USB port | Yes |
Serial interface | Yes |
Cabling technology | 10/100/1000Base-T(X) |
AC outlets quantity | 6 AC outlet(s) |
Number of type F outputs | 6 |
Power plug | C14 coupler |
USB 2.0 ports quantity | 3 |
Serial ports quantity | 1 |
Modem (RJ-11) ports | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Battery |
---|
Number of batteries supported | 2 |
Battery recharge time | 8 h |
Typical backup time at half load | 10 min |
Typical backup time at full load | 4 min |
Battery voltage | 12 V |
Battery capacity | 8.5 Ah |
Design |
---|
Country of origin | China |
Form factor | Tower |
Product colour | Black |
Cooling type | Passive |
LED indicators | Yes |
Display type | LCD |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details |
---|
Output frequency | 50/60 Hz |
Sustainability certificates | RoHS |
Harmonized System (HS) code | 8504408590 |
Compliance certificates | RoHS |
Cooling |
---|
Cooling type | Passive |
Weight & dimensions |
---|
Width | 100 mm |
Depth | 370 mm |
Height | 265 mm |
Weight | 10.9 kg |
Package width | 195 mm |
Package depth | 466 mm |
Package height | 370 mm |
Package weight | 11.6 kg |
Packaging data |
---|
Package width | 195 mm |
Package depth | 466 mm |
Package height | 370 mm |
Package weight | 11.6 kg |
Logistics data |
---|
Harmonized System (HS) code | 8504408590 |
Other features |
---|
Nominal output voltage | 230 V |
