Camera Type | Turret |
Image Sensor | 1/3 Progressive CMOS |
Maximum Video Resolution (Megapixels) | 4 |
Maximum Video Resolution | 2560 x 1440 |
Lens | 2.8 mm (H.FOV: 95) |
Lens Type | Fixed |
Maximum Night IR Distance (M) | 25 |
Video Compression | H.265, H.264, MJPEG |
ONVIF depends on firmware version | ONVIF( Profile S/G/T) 21.12 or greater, Http API |
IP Rating | IP66 |
Operating Environment | -30 +55C/less than 95% RH |
Dimensions | 10090 mm |
Weight (Net) | 0.22 |
Accessories | IV2422X, IV2477X, IV2433X, IV2444X, IV2455X, IV2457X |
Power Supply | Power over Ethernet IEEE 802.3af, DC12V |
Power Consumption | <5W |
Connectors | RJ-45 , DC Power Input |
Outdoor Use | Yes |
IP Rating | IP66 |
Vandal Resistant | Yes |
Frame Rate at Resolution | 25 |
Day/Night Mode | Full color (Auto) |
Image Enhancement | Flip mode, Brightness, Contrast, Saturation, Sharpness, Hue, Mirror, Angle Flip, Back Light, White Balance, Shutter, Time Exposure, Defog, 3D Noise Reduction |
Edge Recording microSD/SDHC Card | Micro SD/SDHC Card |
Multiple Streams (encode format) | 2 Streams |
Audio Streaming | Yes (microphone and speaker included) |
Protocols | TCP/IP, UDP, HTTP, HTTPS, DHCP, FTP, RTP/RTSP, DNS, DDNS, NTP, PPPOE, UPNP, SMTP, SNMP, P2P (QR code) |
Intelligent Video (IVS) | Smart Motion Detection, Perimeter Intrusion Detection, Line Crossing Detection |
Cloud option (camera only) | Dropbox |
Software | Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app (QR code) |
Power Over Ethernet | Yes |
Ethernet | Ethernet (10/100 Base-T) |
In The Box | Printed quick user guide, installation template, mounting screws and plugs |
Warranty | 3 Year Warranty |
