| Audio | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082 |
| Chipset | Intel Z890 Chipset |
| Form Factor | E-ATX Form Factor 12 inch x 10.9 inch (30.5 cm x 27.7 cm) |
| I/O Connectors | Back Panel I/O Ports: 2 x Thunderbolt 5 USB Type-C ports, 1 x USB 20Gbps port (1 x USB Type-C), 7 x USB 10Gbps ports (5 x Type-A + 2 x USB Type-C), 1 x HDMITM port, 1 x Wi-Fi Module, 1 x Intel 2.5Gb Ethernet port, 1 x Marvell AQtion 10Gb Ethernet port, 2 x LED-illuminated audio jacks, 1 x Optical S/PDIF out port, 1 x BIOS FlashBack button, 1 x Clear CMOS button: Front USB (Total 10 ports): 1 x USB 20Gbps connector (supports USB Type-C with up to 60W PD/QC4+), 1 x USB 10Gbps connector (supports USB Type-C), 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports, 2 x USB 2.0 headers support 4 additional USB 2.0 ports |
| Integrated CPU Graphics | 1 x HDMITM port, 2 x Intel Thunderbolt 5 ports (USB Type-C) support DisplayPort and Thunderbolt video outputs |
| LAN | 1 x Intel 2.5Gb Ethernet, 1 x Marvell AQtion 10Gb Ethernet, ASUS LANGuard |
| PCI Slots | Intel Core Ultra Processors(Series 2): 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 or x8/x4/x4 modes); Intel Z890 Chipset: 1 x PCIe 4.0x4 slot |
| Processor Support | Support Intel Core Ultra Processors (Series 2) , LGA1851 |
| RAID | Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5 |
| RAM Type/Bus/Max | 4 x DIMM slots, max. 192GB, DDR5; Support up to 9200+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM), Dual Channel Memory Architecture, Supports Intel Extreme Memory Profile (XMP) memory module, ASUS Enhanced Memory Profile III (AEMP III), Supports DIMM Flex, DIMM Fit, NitroPath DRAM Technology |
| Socket | Support Intel Core Ultra Processors (Series 2) , LGA1851 |
| Storage Interface | Total supports up to 6 x M.2 slots and 4 x SATA 6Gb/s ports |
| Warranty | |
| Weight | |
| Wireless &Bluetooth | Intel Wi-Fi 7, 2x2 Wi-Fi 7 (802.11be), Supports 2.4/5/6GHz frequency band, Support Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate, Bluetooth v5.4 |
