| Audio | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
| Chipset | Intel Z890 Chipset |
| Form Factor | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
| I/O Connectors | Back Panel I/O Ports: 2 x Thunderbolt 4 ports (2 x USB Type-C), 6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-Cwith up to 30W PD/PPD Fast-charge), 2 x USB 5Gbps ports (2 x Type-A), 1 x DisplayPort, 1 x HDMI port, 1 x Wi-Fi module, 1 x Intel 2.5Gb Ethernet port, 2 x Audio jacks, 1 x Optical S/PDIF out port, 1 x BIOS FlashBack button, 1 x Clear CMOS button Front USB (Total 7 ports): 1 x USB 20Gbps connector (supports USB Type-C ), 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports, 2 x USB 2.0 headers support 4 additional USB 2.0 ports |
| Integrated CPU Graphics | 1 x DisplayPort, 1 x HDMI port, 2 x Intel Thunderbolt 4 support DisplayPort and Thunderbolt video outputs |
| LAN | 1 x Intel 2.5Gb Ethernet, ASUS LANGuard |
| PCI Slots | Intel Core Ultra Processors (Series 2): 1 x PCIe 5.0 x16 slot; Intel Z890 Chipset: 1 x PCIe 4.0 x16 slot (supports x4 mode) |
| Processor Support | Support Intel Core Ultra Processors (Series 2), Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 |
| RAID | Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5 |
| RAM Type/Bus/Max | 4 x DIMM slots, max. 192GB, DDR5; Support up to 9066+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM); Dual channel memory architecture; Supports Intel Extreme Memory Profile (XMP) memory module; Supports DIMM Flex; Supports DIMM FIT; ASUS Enhanced Memory Profile III (AEMPIII) |
| Socket | LGA1851 |
| Storage Interface | Total Supports 5 x M.2 slots and 4 x SATA 6Gb/s ports |
| Warranty | |
| Weight | |
| Wireless &Bluetooth | Wi-Fi 7, 2x2 Wi-Fi 7 (802.11be), Supports 2.4/5/6GHz frequency band, Supports Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate, Bluetooth v5.4 |
