| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC |
| Chipset | Intel Z890 Chipset |
| Form Factor | mATX Form Factor 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm |
| I/O Connectors | Back Panel I/O Ports: 1 x USB 20Gbps port (1 x USB Type-C with DP Alt mode), 1x USB 10Gbps port (1 x Type-A), 4 x USB 5Gbps ports (4 x Type-A), 2 x USB 2.0 ports (2 x Type-A), 1 x DisplayPort, 1 x HDMI port, 1 x Wi-Fi module, 1 x Realtek 2.5Gb Ethernet, 3 x Audio jacks, 1 x BIOS FlashBack button; Front USB (Total 7 ports): 1 x USB 5Gbps connector (supports USB Type-C), 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports, 2 x USB 2.0 headers support 4 additional USB 2.0 ports |
| Integrated CPU Graphics | 1 x DisplayPort, 1 x HDMI port, 1 x USB 20Gbps port (USB Type-C) supports DisplayPort video output |
| LAN | 1 x Realtek 2.5Gb Ethernet, ASUS LANGuard |
| PCI Slots | Intel Core Ultra Processors (Series 2): 1 x PCIe 5.0 x16 slot; Intel Z890 Chipset: 1 x PCIe 4.0 x16 slot (supports x4 mode), 2 x PCIe 4.0 x16 slots (support x1 mode) |
| Processor Support | Supports Intel Core Ultra Processors(Series 2), LGA1851 |
| RAID | Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5. |
| RAM Type/Bus/Max | 4 x DIMM slots, max. 192GB, DDR5; Support up to 8666+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM); Dual channel memory architecture; DIMM Fit; Supports Intel Extreme Memory Profile (XMP); ASUS Enhanced Memory Profile III(AEMPIII) |
| Socket | Supports Intel Core Ultra Processors(Series 2), LGA1851 |
| Storage Interface | Total supports 3 x M.2 slots and 6 x SATA 6Gb/s ports |
| Warranty | |
| Weight | |
| Wireless &Bluetooth | Wi-Fi 7, 2x2 Wi-Fi 7 (802.11be), Supports 2.4/5/6GHz frequency band, Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate, Bluetooth v5.4 |
