Performance |
---|
Infrared (IR) cut-off filter | Yes |
Processor model | ARM Cortex-A7 |
Connectivity technology | Wired |
Placement supported | Indoor & outdoor |
Built-in processor | Yes |
Design |
---|
IK code | IK04 |
Form factor | Bullet |
Product colour | Black, White |
Mounting type | Wall/Pole |
International Protection (IP) code | IPX4 |
Housing material | Aluminium, Polycarbonate (PC) |
Camera |
---|
Lens viewing angle, horizontal | 84.4° |
Lens viewing angle, vertical | 45.4° |
Lens viewing angle, diagonal | 99.8° |
Image sensor |
---|
Sensor type | CMOS |
Lens system |
---|
Number of lenses | 1 |
Night vision |
---|
Night vision | Yes |
LED type | IR |
Video |
---|
Noise reduction | Yes |
Image quality adjustment | Brightness, Contrast, Sharpness |
Text caption overlay | Yes |
Privacy masking | Yes |
Noise reduction technology | 2D noise reduction, 3D noise reduction |
Maximum resolution | 2688 x 1512 pixels |
Supported graphics resolutions | 2688 x 1512 |
Supported video modes | 1512p |
Video compression formats | H.264, M-JPEG |
Frame rate | 30 fps |
Total megapixels | 5 MP |
Audio |
---|
Built-in microphone | Yes |
Network |
---|
Bluetooth | No |
Ethernet interface type | 10 Gigabit Ethernet, 100 Gigabit Ethernet |
Ethernet LAN | Yes |
Wi-Fi | No |
Ports & interfaces |
---|
Ethernet LAN (RJ-45) ports | 1 |
Connectivity technology | Wired |
Management features |
---|
Management software | UniFi Protect |
Reset button | Yes |
Power |
---|
Power source type | PoE |
Power consumption (max) | 4 W |
DC output voltage | 57 |
Operational conditions |
---|
Operating temperature (T-T) | -20 - 40 °C |
Operating relative humidity (H-H) | 0 - 90% |
Weight & dimensions |
---|
Diameter | 7.55 cm |
Length | 74.4 mm |
Weight | 225 g |
Sustainability |
---|
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC) |
Packaging content |
---|
Number of cameras | 3 |
Technical details |
---|
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC) |
Other features |
---|
Video compression formats | H.264, M-JPEG |
