90MB1CJ0-M1UAYC | ASUS , PRIME-Z790-P-WIFI-CSM, INTEL, INTEL 12 to 13th

Buy pc parts Techbuy Home Computers Custom PC Systems Tablets Networking Printers Phones Point of Sale Gaming

HOME / Back -> Motherboards -> Intel Socket LGA1700 -> ASUS

ASUS , PRIME-Z790-P-WIFI-CSM, INTEL, INTEL 12 to 13th, LGA1700, 4x DDR5, 128G, Upto 7200+, PCIe 5 - 1x16

Our Price:

$338.80

Qty:

Add To Cart

or quickly purchase this product

Buy Now

In stock for shippingShips from our warehouse in 1-3 business days

Part Number:

548126

(?) Brand:

ASUS Web Site

Manuf No:

90MB1CJ0-M1UAYC
90MB1CJ0M1UAYC

Shipping Weight:

3 KG (Includes product packaging)
Estimate Shipping

Add to wishlist

Write a Review

Details Files Images & Video

All stock codes associated to this product

90MB1CJ0-M1UAYC, 90MB1CJ0M1UAYC, PRIMEZ790PWIFICSM, PRIME-Z790-P-WIFI-CSM

PRIME Z790-P WIFI-CSM

Intel LGA 1700 socket: Ready for 12th and 13th Gen Intel processors
Enhanced power solution: 14+1 DrMOS, 6-layer PCB, ProCool connectors,
alloy chokes and durable capacitors for stable power delivery
Next-gen connectivity: DDR5 memory, Intel Wi-Fi 6, PCIe 5.0,
Realtek 2.5Gb Ethernet, USB 3.2 Gen2x2 Type-C, front panel USB 3.2 Gen 2 Type-C,
Thunderbolt (USB4) header support, 3 PCIe 4.0 M.2
Exclusive Memory Technology: ASUS Enhanced Memory Profile II and ASUS OptiMem II
Comprehensive cooling: Large VRM heatsinks, flexible M.2 heatsink, PCH heatsink,
hybrid fan headers and Fan Xpert 4 with AI Cooling II
ASUS Control Center Express: Real-time IT monitoring and management software for enhanced data protection

Specifications

Audio	Realtek 7.1 Surround Sound High Definition Audio CODEC
Chipset	Intel Z790 Chipset
Form Factor	ATX 30.5 cm x 23.4 cm
I/O Connectors	1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 1 x USB 3.2 Gen 2 port (1 x Type-A) 2 x USB 3.2 Gen 1 ports (2 x Type-A) 4 x USB 2.0 ports (4 x Type-A) 1 x DisplayPort 1 x HDMI port 1 x Wi-Fi Module 1 x Realtek 2.5Gb Ethernet port 3 x Audio jacks 1 x PS/2 Keyboard/Mouse combo port
Integrated CPU Graphics	1 x DisplayPort 1 x HDMI port* Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. * Supports max. 4K@60Hz as specified in DisplayPort 1.4. *** Supports 4K@60Hz as specified in HDMI 2.1.
LAN	Realtek 2.5 Gb LAN
PCI Slots	Intel 13th &12th Gen Processors* 1 x PCIe 5.0 x16 slot Intel Z790 Chipset 3 x PCIe 4.0 x16 slots (support x4 mode) 1 x PCIe 3.0 x1 slot
Processor Support	Intel Socket LGA1700 for 13th Gen Intel Core Processors &12th Gen Intel Core, Pentium Gold and Celeron Processors
RAID	Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10
RAM Type/Bus/Max	4 x DIMM, Max. 128GB, DDR5 7200+(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory
Socket	LGA1700
Storage Interface	Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports
Warranty	3 Years
Weight
Wireless &Bluetooth	Wi-Fi 6 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) Supports 2.4/5GHz frequency band Bluetooth v5.2

No additional files, specification sheets, guides or documentation found for product.

Warranty: 12 Month Return To Base

Full manufacturers warranty details are available at the manufacturers (ASUS) web site.

Unless otherwise specified Techbuy is normally your first point of contact for warranty related returns, further information regarding our warranty policies and consumer guarantees is available on our policies and service & support pages.

To apply for return of a product just go to our returns page.

These terms are in addition to and do not affect any terms, conditions, guarantees and warranties implied by law.
