| Audio | Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC |
| Chipset | AMD X870 Chipset |
| Form Factor | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm |
| I/O Connectors | Back Panel I/O Ports: 2 x USB4 (40Gbps) (2 x USB Type-C) ports, 3 x USB 10Gbps ports (3 x Type-A), 4 x USB 5Gbps ports (4 x Type-A), 1 x USB 2.0 port (1 x Type-A), 1 x HDMI port, 1 x Wi-Fi module, 1 x Realtek 2.5Gb Ethernet port, 5 x Audio jacks, 1 x BIOS FlashBack button; Front USB (Total 7 ports): 1 x USB 20Gbps connector (supports USB Type-C with up to 30W PD Fast-charge), 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports, 2 x USB 2.0 headers support 4 additional USB 2.0 ports |
| Integrated CPU Graphics | 1 x HDMI port, 2 x USB4 (40Gbps) ports support USB Type-C display outputs |
| LAN | 1 x Realtek 2.5Gb Ethernet, TUF LANGuard |
| PCI Slots | AMD Ryzen 9000 &7000 Series Desktop Processors: 1 x PCIe 5.0 x16 slot (supports x16 mode), AMD Ryzen 8000 Series Desktop Processors: 1 x PCIe 4.0 x16 slot (supports x8/x4 mode), AMD X870 Chipset: 1 x PCIe 4.0 x16 slot (supports x4 mode) |
| Processor Support | AMD Socket AM5 for AMD Ryzen 9000 &8000 &7000 Series Desktop Processors |
| RAID | AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1. RAID 5 Function is only supported by AMD Ryzen 9000 series CPU. |
| RAM Type/Bus/Max | 4 x DIMM slots, max. 192GB, DDR5, Supports up to 8000+MT/s(OC) with Ryzen 9000 &8000 &7000 Series Processors, ECC and Non-ECC, Un-buffered DIMM, Dual channel memory architecture, Supports AMD Extended Profiles for Overclocking (EXPO), ASUS Enhanced Memory Profile (AEMP) |
| Socket | AMD Socket AM5 for AMD Ryzen 9000 &8000 &7000 Series Desktop Processors |
| Storage Interface | Total Supports 4 x M.2 slots and 2 x SATA 6Gb/s ports |
| Warranty | 3 Years |
| Weight | |
| Wireless &Bluetooth | Wi-Fi 7, 2x2 Wi-Fi 7 (802.11be), Supports 2.4/5/6GHz frequency band, Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate, Bluetooth v5.4 |
