| Audio | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
| Chipset | AMD X870E |
| Form Factor | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
| I/O Connectors | Back Panel I/O Ports: 2 x USB4 (40Gbps) ports (2 x USB Type-C), 1 x USB 20Gbps port (1 x USB Type-C with up to 30W PD Fast-charge), 10 x USB 10Gbps ports (9 x Type-A + 1 x USB Type-C), 1 x HDMI port, 1 x Wi-Fi Module, 1 x Realtek 5Gb Ethernet, 2 x Gold-plated audio jacks, 1 x Optical S/PDIF out port, 1 x BIOS FlashBack button, 1 x Clear CMOS button; Front USB (Total 11 ports): 1 x USB 20Gbps connector (supports USB Type-C), 2 x USB 5Gbps headers support additional 4 USB 5Gbps ports, 3 x USB 2.0 headers support additional 6 USB 2.0 ports |
| Integrated CPU Graphics | 1 x HDMI port, 2 x USB4 (40Gbps) ports support USB Type-C display outputs |
| LAN | 1 x Realtek 5Gb Ethernet, ASUS LANGuard |
| PCI Slots | AMD Ryzen 9000 &7000 Series Desktop Processors: 1 x PCIe 5.0 x16 slot (supports x16 mode); AMD Ryzen 8000 Series Desktop Processors: 1 x PCIe 4.0 x16 slot (supports x8/x4 mode); AMD X870E Chipset: 1 x PCIe 4.0 x16 slot (supports x4 mode) |
| Processor Support | AMD Socket AM5 for AMD Ryzen 9000 &8000 &7000 Series Desktop Processors |
| RAID | |
| RAM Type/Bus/Max | 4 x DIMM slots, max. 192GB, DDR5; Supports up to 8000+MT/s(OC) with Ryzen 9000 Series Processors, 8400+MT/s(OC) with Ryzen 8000 Series Processors, 8000+MT/s(OC) with Ryzen 7000 Series Processors; ECC and Non-ECC Un-buffered DIMM; Dual Channel Memory Architecture; Supports AMD EXTended Profiles for Overclocking (EXPO); NitroPath DRAM Technology; ASUS Enhanced Memory Profile (AEMP) |
| Socket | AMD Socket AM5 for AMD Ryzen 9000 &8000 &7000 Series Desktop Processors |
| Storage Interface | Total supports 5 x M.2 slots and 4 x SATA 6Gb/s ports |
| Warranty | |
| Weight | |
| Wireless &Bluetooth | Wi-Fi 7, 2x2 Wi-Fi 7 (802.11be), Supports 2.4/5/6GHz frequency band, Support Wi-Fi 7 320MHz bandwidth, up to 6.5Gbpstransfer rate, Bluetooth v5.4 |
