Performance |
---|
Preset points | Yes |
Infrared (IR) cut-off filter | Yes |
Number of languages | 11 |
Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Portuguese, Russian |
Processor model | ARTPEC-7 |
Type | IP security camera |
Connectivity technology | Wireless |
PTZ control | Yes |
Placement supported | Indoor & outdoor |
Auto-tracking | Yes |
Tour recording | Yes |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
Design |
---|
IK code | IK10 |
Form factor | Dome |
Product colour | Black, White |
Mounting type | Wall |
International Protection (IP) code | IP66, IP67 |
Housing material | Aluminium, Polycarbonate (PC) |
Camera |
---|
Minimum illumination | 0.1 lx |
Tilt angle range | 0 - 220° |
Tilt speed | 450 °/sec |
Pan range | 0 - 360° |
Pan speed | 450 °/sec |
Camera shutter speed | 1/11000 - 1/3 s |
Camera pan control | Yes |
Camera tilt control | Yes |
Lens viewing angle, horizontal | 65.1 – 2.00 |
Lens viewing angle, vertical | 39.1 – 1.18 |
Progressive scan | Yes |
Image sensor |
---|
Sensor type | CMOS |
Progressive scan | Yes |
Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Number of sensors | 1 |
Lens system |
---|
Number of lenses | 1 |
Maximum aperture number | 4.95 |
Auto focus | Yes |
Minimum aperture number | 1.6 |
Zoom capability | Yes |
Optical zoom | 40x |
Digital zoom | 12x |
Focal length range | 4.25 - 170 mm |
Night vision |
---|
Night vision | Yes |
Video |
---|
Image quality adjustment | Brightness, Colour depth, Sharpness |
Text caption overlay | Yes |
Privacy masking | Yes |
Back Light Compensation (BLC) | Yes |
Maximum resolution | 1920 x 1080 pixels |
Supported graphics resolutions | 320 x 180, 1920 x 1080 (HD 1080) |
Supported video modes | 1080p |
Video compression formats | H.264, H.265 |
Frame rate | 60 fps |
Video streaming | Yes |
Video recording | Yes |
Network |
---|
Bluetooth | No |
Networking standards | IEEE 802.1x |
Quality of Service (QoS) support | Yes |
Ethernet LAN | Yes |
Wi-Fi | No |
Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPSa , TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, NTCIP, LLDP, CDP, MQTT, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
Storage |
---|
Card reader integrated | Yes |
Compatible memory cards | SD, SDHC, SDXC |
Built-in HDD | No |
Internal memory | 1024 MB |
Flash memory | 512 MB |
Ports & interfaces |
---|
Ethernet LAN (RJ-45) ports | 1 |
Connectivity technology | Wireless |
Security |
---|
Alert notification type | E-mail |
Video motion detection | Yes |
IP address filtering | Yes |
HTTPS encryption | Yes |
Password protection | Yes |
Pixel counter | Yes |
Digest authentication | Yes |
Power |
---|
Power source type | AC, PoE |
Power consumption (Power over Ethernet (PoE)) | 60 W |
AC input voltage | 100 - 240 V |
Power consumption (typical) | 14 W |
Power consumption (max) | 66.1 W |
Operational conditions |
---|
Operating temperature (T-T) | -20 - 50 °C |
Storage temperature (T-T) | -40 - 65 °C |
Operating relative humidity (H-H) | 10 - 100% |
Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions |
---|
Height | 271 mm |
Diameter | 23.2 cm |
Weight | 3.75 kg |
Packaging content |
---|
Number of cameras | 1 |
Manual | Yes |
Technical details |
---|
Doesn't contain | PVC |
Warranty period | 5 year(s) |
Other features |
---|
Video compression formats | H.264, H.265 |
Doesn't contain | PVC |
Warranty period | 5 year(s) |
