| Internal I/O |
|---|
| Number of M.2 (M) slots | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 0 |
| 12V power connector | Yes |
| Supported storage drive interfaces | M.2, SATA III |
| USB 2.0 connectors | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| mSATA ports quantity | 0 |
| Number of SATA III connectors | 2 |
| Number of SATA II connectors | 0 |
| Number of SATA connectors | 0 |
| Number of chassis fan connectors | 1 |
| EPS power connector (8-pin) | Yes |
| CPU fan connector | Yes |
| ATX Power connector (24-pin) | Yes |
| USB 3.2 Gen 2x2 connectors | 1 |
| Number of CPU fan connectors | 1 |
| Performance |
|---|
| Number of HDDs supported | 2 |
| Supported storage drive types | HDD & SSD |
| Component for | PC |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel Z890 |
| Motherboard form factor | mini ITX |
| RAID levels | 0, 1 |
| Windows operating systems supported | Windows 11 |
| Processor |
|---|
| Processor manufacturer | Intel |
| Compatible processor series | Intel Core Ultra (Series 2) |
| Processor socket | LGA 1851 (Socket V1) |
| Memory |
|---|
| Number of memory slots | 2 |
| Supported memory types | DDR5-SDRAM |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| Maximum internal memory | 96 GB |
| Unbuffered memory | Yes |
| ECC Ñompatibility | Non-ECC |
| Storage controllers |
|---|
| Number of HDDs supported | 2 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
| RAID levels | 0, 1 |
| Number of storage drives supported | 4 |
| RAID support | Yes |
| Graphics |
|---|
| Parallel processing technology support | Not supported |
| On-board graphics card | No |
| Rear panel I/O ports |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| VGA (D-Sub) ports quantity | 0 |
| Thunderbolt ports quantity | 2 |
| HDMI ports quantity | 1 |
| DVI-D ports quantity | 0 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Network |
|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Features |
|---|
| Component for | PC |
| Motherboard chipset family | Intel |
| Motherboard chipset | Intel Z890 |
| Motherboard form factor | mini ITX |
| Windows operating systems supported | Windows 11 |
| Product colour | Black |
| Expansion slots |
|---|
| Number of M.2 (M) slots | 2 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| BIOS |
|---|
| BIOS type | UEFI AMI |
| BIOS memory size | 256 Mbit |
| Weight & dimensions |
|---|
| Width | 170 mm |
| Depth | 170 mm |
| Other features |
|---|
| mSATA ports quantity | 0 |
