| Performance |
|---|
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 33 |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| People counting function | Yes |
| Design |
|---|
| IK code | IK10 |
| Camera |
|---|
| Minimum illumination | 0.001 lx |
| Tilt angle range | 0 - 75° |
| Pan range | 0 - 355° |
| Camera shutter speed | 1/100 s |
| Progressive scan | Yes |
| Image sensor |
|---|
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Lens system |
|---|
| Maximum aperture number | 12 |
| Auto focus | Yes |
| Minimum aperture number | 2.8 |
| Focus | Motorized/Manual |
| Night vision |
|---|
| Infra-red wavelength | 850 nm |
| Video |
|---|
| Image quality adjustment | Saturation, Brightness, Contrast, Sharpness, DNR |
| Smart IR | Yes |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | 32 Kbps - 16 Mbps |
| Back Light Compensation (BLC) | Yes |
| Maximum resolution | 2680 x 1520 pixels |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Video streaming | Yes |
| Audio |
|---|
| Voice codecs | G.711, G.722.1, G.726, MP2L2, PCM |
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Sample rate | 48 kHz |
| Network |
|---|
| Ethernet interface type | Fast Ethernet |
| Number of users | 32 user(s) |
| Ethernet LAN | Yes |
| Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Storage |
|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), SDHC, SDXC |
| Maximum memory card size | 256 GB |
| Ports & interfaces |
|---|
| Terminal block port | Yes |
| RS-485 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Composite video out | 1 |
| Connectivity technology | Wired |
| Security |
|---|
| Motion sensor | Yes |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Heartbeat | Yes |
| Anti-flicker | Yes |
| Management features |
|---|
| Web browser | Yes |
| Firmware upgradeable | Yes |
| Power |
|---|
| Power source type | DC |
| DC output voltage | 12 |
| Operational conditions |
|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Weight & dimensions |
|---|
| Diameter | 14.1 cm |
| Length | 122.6 mm |
| Weight | 950 g |
| Package width | 244 mm |
| Package depth | 174 mm |
| Package height | 173 mm |
| Package weight | 13 kg |
| Packaging data |
|---|
| Package width | 244 mm |
| Package depth | 174 mm |
| Package height | 173 mm |
| Package weight | 13 kg |
| Sustainability |
|---|
| Compliance certificates | RoHS |
| Packaging content |
|---|
| Manual | Yes |
| Technical details |
|---|
| Compliance certificates | RoHS |
| Other features |
|---|
| Focus | Motorized/Manual |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
